Logitech Tap Scheduler 2 For Meeting Rooms (Graphite)
LogitechPricing available upon request
Up to 5 year(s) limited warranty against manufacturer defects from Logitech Singapore with extended warranty plans. Up to 2 year(s) with standard warranty. During the warranty period, the manufacturer's appointed authorised service centre will, at its sole discretion (a) repair the product using new or refurbished parts, (b) replace the product with a new or refurbished product.
The Logitech Tap Scheduler 2 improves upon the previous scheduling interface with a brighter screen with higher resolution for better visibility in the office. The 10.1" IPS touchscreen features an anti-fingerprint oleophobic coating, 1920 x 1200 resolution, and 1500:1 contrast ratio for increased visibility. With red and green LED borders, it's easy to see if a room is available at a distance. Control and power for the device is provided via Ethernet cable. Additional wireless connectivity includes WiFi and Bluetooth 5.0.
Intuitive Visuals
Quickly identify if a room is available using the red and green LED border. The touchscreen display wakes up as you approach, allowing you to quickly reserve the room with just a tap.
Wide Compatibility
The Tap Scheduler 2 works in tandem with leading management platforms like Microsoft Teams, Zoom Workspace Reservation, Appspace, and Logitech Room Booking.
Versatile Installation
Install the Tap Scheduler 2 outside of any room using the included multi-surface mount—which works for glass and drywall surfaces—or the mullion mount. Power and communication are facilitated via single Ethernet cable for reduced cable runs.
Key Features
- Mounts Outside Conference/Meeting Rooms
- On-Screen Room Info & Booking Interface
- 10.1" IPS Touchscreen Display
- Green/Red Room Availability Border
- WiFi, Bluetooth, Ethernet Connectivity
- Multi-Surface & Mullion Mounts Included
Technical Specifications
- Display
- Size: 10.1” diagonal, IPS (in-plane switching) anti-glare LCD Panel with LED backlighting
- Resolution: 1920 x 1200
- Touch: Capacitive, 10 points multi-touch
- Brightness: 380 nits
- Contrast: 1500:1
- Anti Fingerprint: Oleophobic coating
- Viewing angle: 80° (up/down/left/right)
- Position angle: 0° (flat on mounting surface)
- Ports & Interfaces
- Ethernet: 10/100mbps
- WiFi: 802.11a/b/g/n/ac/ax
- Bluetooth: 5.0
- Mounting Pattern: 100mm x 100mm VESA FDMI
- Electrical & Environmental
- Power supply: Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device. *Requires PoE enabled network or PoE Injector and ethernet cable (Not included)
- Operating Temperature: 0 to 40°C
- Storage Temperature: -40 to 70°C
- Humidity: 10-95%
- Security
- Full Disk Encryption: AES-128
- Data Encryption: Symmetric Keys, PKI
- Device Identity: Protected by device attestation
- Key Protection: Arm TrustZone
- Device Security: Kensington Lock
- Built on MDEP: Yes
- General Specifications
- Operating Systems: Logitech CollabOS
- Device Management: Monitor and manage with Logitech Sync, Microsoft Teams Admin Center, and Zoom Device
- Management platforms.
- Cable exits: Horizontal / vertical / center
- Sensors: Accelerometer, ambient light, radar motion sensors
- Dimensions
- Device-only
- Height: 165 mm
- Width: 246.2 mm
- Depth: 28.5 mm
- Surface-mounted
- Height: 165 mm
- Width: 246.2 mm
- Depth: 31.4 mm
- Mullion-mounted
- Height: 165 mm
- Width: 292.6 mm
- Depth: 44.5 mm
- Device-only
- Product Type:
- Video Conferencing
- Meeting Room Size:
- Small
- Meeting Room Size:
- Medium
- Meeting Room Size:
- Large
