Kramer VP-426 HDMI/Computer Graphics Video & HDTV ProScale Digital Scaler

The VP−426 is a high−performance digital scaler for computer graphics/HDTV and HDMI signals. The unit up− or down−scales computer graphics and HDTV signals to resolutions of up to WUXGA and 1080p.

•  Inputs — RGBHV, YPbPr or HDMI.
•  Outputs — RGBHV and HDMI simultaneously.
•  HDTV Compatible.
•  HDCP Compliant.
•  Input Auto–Scanning.
•  EDID Capture — Copies and stores the EDID from a display device.
•  Analog/Embedded Audio Support.
•  Built–In ProcAmp — Color, hue, sharpness, contrast, and brightness controls.
•  Control — Front panel, OSD (on screen display), contact closure.
•  Non–Volatile Memory — Saves final settings.
•  Freeze Button.
•  Contact Closure — For remote switching of sources.
•  USB Port — For upgrading firmware.

Key Features

• Input Auto–Scanning
• Built–In ProcAmp
• Control — OSD (on screen display) & contact closure

Technical Specifications

• Inputs: 1 PC/HD (RGBHV/YPbPr) on a 15–pin HD connector, 1 HDMI connector, 2 unbalanced stereo audio connectors on 3.5mm mini jacks
• Outputs: 1 PC (RGBHV) on a 15–pin HD connector, 1 HDMI connector, 1 unbalanced stereo audio connector on a 3.5mm mini jack
• Input Resolutions:

  • Component: 480i, 576i, 480p, 576p, 720p@60Hz, 720p@50Hz, 1080i@60Hz, 1080i@50Hz, 1080p@60Hz, 1080p 50Hz, 1080p@24Hz, 1080p@25Hz, 1080p@30Hz
  • PC: VGA@60Hz, VGA@67Hz, VGA@72Hz, VGA@75Hz, VGA@85Hz, SVGA@56Hz, SVGA@60Hz, SVGA@72Hz, SVGA@75Hz, XGA@60Hz, XGA@70Hz, XGA@75Hz, SXGA@60Hz, SXGA@75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz (UXGA), 1280x800@60Hz (WXGA), 1440x900@60Hz (WXGA+), 1366x768@60Hz (WXGA), 1400x1050@60Hz (SXGA+), 1680x1050@60Hz RB (WSXGA), 1920x1200@60Hz RB (WUXGA)
  • HDMI: 480i, 576i, 480p, 576p, 720p@60Hz, 720p@50Hz, 1080i@60Hz, 1080i@50Hz, 1080p@60Hz, 1080p@50Hz, 1080p@24Hz, 1080p@25Hz , 1080p@30Hz, VGA@60Hz, VGA@67Hz, VGA@72Hz, VGA@75Hz, VGA@85Hz, SVGA@56Hz, SVGA@60Hz, SVGA@72Hz, SVGA@75Hz, XGA@60Hz, XGA@70Hz, XGA@75Hz, SXGA@60Hz, SXGA@75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz (UXGA), 1280x800@60Hz (WXGA), 1440x900@60Hz (WXGA+), 1366x768@60Hz (WXGA), 1400x1050@60Hz (SXGA+), 1600X900@60Hz RB, 1680x1050@60Hz RB (WSXGA), 1920x1200@60Hz RB (WUXGA)
• Output Resolutions: NATIVE, 480i, 480p, 720p@60Hz, 1080i@60Hz, 1080p@60Hz, 576i, 576p, 720p@50Hz, 1080i@50Hz, 1080p@50Hz, 640x480, 800x600, 1024x768, 1280x1024, 1600x1200, 1366x768, 1680x1050, 1920x1200, 1280x800, 1440x900, 1400x1050, 1600x900
• Output Refresh Rate: 60Hz for computer graphics resolutions, 50/60Hz for HDTV resolutions
• Video Latency:

  • Progressive input: 30ms (approx.)
  • Interlaced input: 50ms (approx.)
• Controls: Front panel buttons, 1 remote contact closure on a 3–pin terminal block connector, 1 USB for programming
• Indicators: ON, HDMI and PC LEDs
• Power Consumption: 5V DC, 1.1A
• Operating Temperature: 0° to +40°C (32° to 104°F)
• Storage Temperature: –40° to +70°C (–40° to 158°F)
• Humidity: 10% to 90%, RHL non–condensing
• Product Dimensions: 19.00cm x 11.60cm x 2.70cm (7.48" x 4.57" x 1.06" ) W, D, H
• Product Weight: 0.5kg (1.0lbs) approx.
• Shipping Dimensions: 34.50cm x 16.50cm x 5.20cm (13.58" x 6.50" x 2.05" ) W, D, H
• Shipping Weight: 1.0kg (2.1lbs) approx.

What's Included

• Power supply
