Warranty: 1 Year
The Cisco IP Conference Phone 8832 enhances people-centric collaboration by delivering easy-to-use audio conferencing with astounding voice quality and clarity. Newly developed microphones and loudspeakers provide the richest sound of any conference phone on the market. Our unique acoustic design includes a “studio-monitor” full-range speaker. This loudspeaker architecture provides a dynamic, detailed sound with low distortion and low-frequency clarity, making conferencing an in-person experience with exceptionally clear and natural audio quality.
The Cisco IP Conference Phone 8832 provides a simple, flexible, scalable solution that meets the challenges of the most diverse rooms. With the base unit alone, it provides 360-degree coverage for any 20x20-foot room and up to 10 participants. With the optional wired extension microphone kit, it covers any 20x34-foot room and up to 22 participants. With the optional wireless extension microphone kit (using Digital Enhanced Cordless Telecommunications [DECT] technology), it covers any 20x40-foot room and up to 26 participants. With a daisy-chain configuration of two 8832 units along with the optional wireless extension microphone kit, it covers up to a 20x57-foot room and up to 42 participants. It is ideal for executive offices, conference rooms, and boardrooms.
The 8832 unit has a sleek form by using approachable materials for a differentiated, modern look and feel. The key design elements include the following:
● 3.9-inch 480x128-pixel color LCD
● Textile cover for soft touch and durability
● Large mute button in the middle of the device for easy access from all angles
● LED indicator above the mute button showing the call status
● Raised edge for easier handling and repositioning on tabletop
● Crisp, precise button tactility
● Single USB-C port on the device to minimize the number of cables on the table (an Ethernet injector is required for any non-Wi-Fi deployment)
The optional wired microphone kit includes two wired microphones with anodized aluminum top housing.
The key features of this conference phone are as follows:
● 360-degree room coverage; base unit alone covers up to a 10-foot microphone pickup range
● Single line with a user experience of multiple calls per line
● Session Initiation Protocol (SIP) signaling
● Codec support, including G.711(u/A), G.729a, G.729ab, iLBC, G.722, and OPUS
● IPv6 support
● Secure Hash Algorithm (SHA)-256 enabled for advanced security features
● Mobile and Remote Access (MRA) support
● Wi-Fi support
● Wired extension microphone support
● Wireless extension microphone support
● Daisy-chain support
● Client Matter Code (CAC) and Forced Authorization Code (FAC) Support
● Compatible with both IEEE 802.3af and 802.3at Power over Ethernet (PoE) Class 3 consumption (both PoE and non-PoE Ethernet injector options are available)
Technical Specifications
|
Feature |
Specifications |
|
Audio |
G.711 a-law and mu-law, wideband (G.722), G.729a, G.729ab, Internet Low Bitrate Codec (iLBC), OPUS Automatic Gain Control Comfort Noise Generation Silence Suppression/Voice Activity Detection Echo Suppression Dynamic Noise Reduction |
|
Acoustics |
Frequency: Speaker, 100 Hz to 20 kHz; microphones, 100 Hz to 12 kHz, ±3 dB Max adjustable volume: 89 dB within 0.5 m |
|
Call features |
● + Dialing
● Adjustable ring tones and volume levels
● Barge
● Call forward
● Call history lists
● Call park
● Call timer
● Call waiting
● Caller ID
● Corporate directory
● Conference
● Hold
● Music on Hold (MoH)
● Mute
● Predialing before sending
● Redial
● Shared line
● Speed dial (Favorites)
● Time and date display
● Transfer
● Voicemail (messages)
|
|
Quality-of-Service (QoS) options |
The phone supports Cisco Discovery Protocol and 802.1Q/p standards and can be configured with an 802.1Q VLAN header containing the VLAN ID overrides configured by the admin VLAN ID. |
|
Network features |
● Session Initiation Protocol (SIP) for signaling
● Session Description Protocol (SDP)
● IPv4
● IPv6
● User Datagram Protocol (UDP) (used only for Real-Time Transport Protocol streams)
● Dynamic Host Configuration Protocol (DHCP) client or static configuration
● Gratuitous Address Resolution Protocol (GARP)
● Domain Name System (DNS)
● Trivial File Transfer Protocol (TFTP)
● Secure HTTP (HTTPS)
● VLAN
● Real-Time Transport Protocol (RTP)
● Real-Time Control Protocol (RTCP)
● Cisco Discovery Protocol
● LLDP (including LLDP-MED)
● Switch speed auto-negotiation
|
|
Security features |
● Secure credential storage
● Image authentication
● Random bit generation
● Manufacturer-Installed Certificates (MICs )
● Secure boot
● SHA-256 enabled for advanced security features
● Ethernet 802.1X supplicant options: Extensible Authentication Protocol – Flexible Authentication via Secure Tunneling (EAP-FAST) and Extensible Authentication Protocol – Transport Layer Security (EAP-TLS)
● Signaling authentication and encryption using TLS v1.2
● Media authentication and encryption using SRTP
● HTTPS for client and server
● Secure Shell (SSH) Protocol server
|
|
Physical dimensions |
10.9 x 10.9 x 2.4 in. (278 x 278 x 61 mm) |
|
Weight |
4.07 lb (1.85 kg) |
|
Phone-casing composition |
Acrylonitrile Butadiene Styrene (ABS) textured plastic; Cisco cosmetic class A |
|
Operational temperature |
32° to 104°F (0° to 40°C) |
|
Nonoperational temperature shock |
14° to 140°F (–10° to 60°C) |
|
Humidity |
● Operating 10% to 90%, noncondensing
● Nonoperating 10% to 95%, noncondensing
|
|
Language support |
● Arabic (Arabic Area)
● Bulgarian (Bulgaria)
● Catalan (Spain)
● Croatian (Croatia)
● Czech (Czech Republic)
● Danish (Denmark)
● Dutch (Netherlands)
● English (United Kingdom)
● Estonian (Estonia)
● French (Canada)
● French (France)
● Finnish (Finland)
● German (Germany)
● Greek (Greece)
● Hebrew (Israel)
● Hungarian (Hungary)
● Italian (Italy)
● Japanese (Japan)
● Korean (Korea Republic)
● Latvian (Latvia)
● Lithuanian (Lithuania)
● Norwegian (Norway)
● Polish (Poland)
● Portuguese (Portugal)
● Portuguese (Brazil)
● Romanian (Romania)
● Russian (Russian Federation)
● Serbian (Republic of Serbia)
● Serbian (Republic of Montenegro)
● Simplified &Traditional Chinese (China)
● Slovak (Slovakia)
● Slovenian (Slovenia)
● Spanish (Columbia)
● Spanish (Spain)
● Swedish (Sweden)
● Thai (Thailand)
● Turkish (Turkey)
● Ukrainian (Ukraine)
|
|
Certifications and compliance |
● Regulatory compliance
◦ CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU
● Safety
◦ UL 60950 Second Edition
◦ CAN/CSA-C22.2 No. 60950 Second Edition
◦ EN 60950 Second Edition (including A11 and A12)
◦ IEC 60950 Second Edition (including A11 and A12)
◦ EN 60950-1
◦ IEC 60950-1
◦ AS/NZS 60950.1
● EMC – Emissions
◦ 47CFR Part 15 (CFR 47) Class B
◦ AS/NZS CISPR32 Class B
◦ CISPR32
Class B
◦ EN55032
Class B
◦ EN 300 386
◦ ICES003 Class B
◦ VCCI Class B
◦ EN61000-3-2
◦ EN61000-3-3
◦ EN61000-4-2
◦ IEC61000-4-2
◦ EN61000-4-3
◦ IEC61000-4-3
◦ EN61000-4-6
◦ IEC61000-4-6
◦ KN22 Class B
● EMC – Immunity
◦ EN55024
◦ CISPR24
◦ KN24
◦ Armadillo Light
● Telecom
◦ AS/ACIF S004
◦ NZPTC220
◦ Industry standards: TIA 810 B and TIA 920 A
◦ Industry standards: IEEE 802.3 Ethernet, IEEE 802.3af and 802.3at
● Radio
◦ FCC Part 2.1093 (BT RF Exposure TR)
◦ RSS-102 (BT RF Exposure TR)
◦ RSS-210
◦ RSS-213
◦ RSS-247
◦ EN 300 328
◦ EN 300 440
◦ EN 301 406
◦ EN 50385 (BT RF Exposure TR)
◦ EN 301-489-1
◦ EN 301-489-3
◦ EN 301-489-6
◦ EN 301-489-17
◦ EN 301 893
◦ NCC LP0002
|
- Product Type:
- Conference Phone
