ViewSonic Wireless Module for ViewBoard & Wireless Presentation Display With Wi-Fi 6 Connectivity

ViewSonic
SKU:
VB-WIFI-001

Pricing available upon request

Warranty: 5 Years
Current Stock:

VB-WIFI-001

The ViewSonic® VB-WIFI-001 wireless module delivers a fast wireless internet connection for ViewBoard and Wireless Presentation Display*. It supports dual-frequency 2.4GHz and 5GHz bandwidth, along with Wifi 6 (802.11ax standard). *Compatible with selected models, please check with your local sales representatives

Faster Connections

An optional Wifi module for the ViewBoards and Wireless Presentation Display* to help run lessons smoothly and get a more interactive discussion in the office. Wifi 6 offers faster internet speeds for the ever more bandwidth-demanding applications like video conferences, live streaming, and connected device networks. *Compatible with selected models, please check with your local sales representatives

Faster Connections 1

Dual Band Wireless Support

Supporting both 2.4 and 5 GHz dual-band wireless transmission helps users adjust settings to their needs. A 2.4 GHz connection travels farther at lower speeds, while 5 GHz frequencies provide faster speeds at a shorter range. Smoothly streams multimedia content such as videos and images without any delays.

Dual Band Wireless Support 1

Key Features

  • Wi-Fi 6
  • Bluetooth 5 Support
  • Dual Band Wireless Support

Technical Specifications

  • Wifi Standard: 802.11 a/b/g/n/ac/a

  • Bluetooth: Support 2.1/3.0/4.0/5.2 BLE
  • Power
    • Requirements: 5V DC, 0.9A
    • Consumption:< 4.5W
  • Dimension
    • Physical: 3.90x0.43x3.03 in / 99x11x77mm
    • Packaging: 3.54x0.63x6.18 in / 90x16x157mm
  • Weight
    • Net: 0.07lb / 30g
    • Gross: 0.18lb / 80g
  • Operating Condition
    • Temperature: 32°F to 104°F (0°C to 40°C)
    • Humidity: 10% ~ 90% non-condensing
  • Compliance: FCC, FCC ID, IC ID, CE, RCM
Product Type:
Display
