ViewSonic TD1655 16" Full HD 1080p USB-C Touch Portable Monitor

ViewSonic
SKU:
TD1655
|
UPC:
766907007077

Pricing available upon request

Warranty: LCD Monitors 3 years on-site for parts & labour
Current Stock:

The ViewSonic TD1655 is a portable 16” Full HD touch monitor perfect for overcoming one-screen limitations outside the office. Extend the screen from phones, tablets, or laptops for mobile work, one-on-one presentations, or leisure entertainment. The two universal USB Type C connectors provide a one-cable solution for audiovisual, power, and touch signal transmission. The adjustable wide stand and pivot-able display will support your working angles. With the anti-slip cover, metal case, aluminum stand, and 6H hardness screen, reliability is embodied in the design.

Extend your content from mobile devices
Extend your screen anywhere with your built-in USB Type C laptop, tablet, or phone. It supports Windows, Android, Chrome, MacOS, iOS and iPadOS*. Be sure your laptop, tablet, or smartphone has a full-function USB-C connector that supports Display Port 1.2 Alt Mode.

*To connect on iPhone or iPad with a lightning port, you will require to purchase a Lightning Digital AV Adapter from apple.com and connect via a HDMI to mini HDMI cable**.
**The HDMI to mini HDMI cable is included in the box.
***Full-featured USB-C connector implements Video, Audio, USB touch data transmission and power delivery.
Anywhere with Laptops, Tablets, and Phones
Extend your content from mobile devices 1

Audiovisual Extension while Power Charging
Broadcast your built-in Type C mobile device’s multimedia onto a bigger screen and charge (up to 60W) over one cable while powering from an external power bank/outlet over the other USB Type C cable.

*Power Charging:
1. For longer use, connect to an external power bank or outlet.
2. For temporary use, connect to your mobile device only.
1> Over 2 hours when powering from your phone - Tested with the phone's built-in battery at a capacity of 4,000 mAh.
a. The phone is on, but with a blank screen.
b. The portable monitor has a brightness value of 15 and a contrast value of 70.
c. Connected by a USB Type C cable.

2> Over 1.5 hours when powering from your laptop - Tested with the laptop's built-in battery at a capacity of 53,546 mAh.
a. The laptop is on; the screen is on.
b. The portable monitor has a brightness value of 100 and a contrast value of 70.
c. Connected by a USB Type C cable.
Flexible Setup with 2 x USB Type C
Audiovisual Extension while Power Charging 1

Touch Feedback Control
Control in a large screen with touch gives more intuitive and efficient reactions. The attached magnetic touch pen allows you to draw and write notes without leaving fingerprints.

*Touch feedback control does not apply to iOS & iPadOS devices.
*Please download vTouch software to enable touch feedback on MacOS.
*Please check if the connectivity on your mobile device supports USB touch signal transmission to enable touch feedback control to our monitor.
*Do not remove the plastic disc from the tip of the pen as it is instrumental to touch accuracy functionality.
10-Point Fingertip/Touch Pen
Touch Feedback Control 1

Portable Size for Work & Fun
Larger, 16” display than most common laptops and weighing less than 1 kg. It perfectly outfits your mobile workplace, and can be used for multimedia play when taking a break.
16” Display, 1 KG, 1 CM
Portable Size for Work & Fun 1

Working in Your Preferred Angles
View in a wide range of angles by adjusting the attached stand.
Up to 60 Degree Tilt
Working in Your Preferred Angles 1

Supports Vertical Layout
Besides common horizontal content, you may setup a pivot screen for table-reviewing, programming, photo-editing, gaming, etc.
Pivot-able Display
Supports Vertical Layout 1

Magnetic Cover and Mat
Avoid damage during carry, the detachable magnetic cover is easy to put on. Used as a mat, its anti-slip surface prevents the monitor from sliding away.
Anti-slip Cover
Magnetic Cover and Mat 1

Robust One-piece Design
With the metal case and endurable hinge, the fold-able aluminum stand makes the whole monitor a one-piece design.
Metal Case & Aluminum Stand
Robust One-piece Design 1

Anti-scratch Touch Screen
Built-in 6H hardness screen, it’s resistant to surface damage, even if accidently scratched by your keys.
6H Hardness Screen
Anti-scratch Touch Screen 1

Dimensions & I/O Ports
  1. USB Type C x2
  2. Mini HDMI
  3. Audio Out
  4. Joy Key

Key Features

  • Easily extend your content from laptops and mobile devices
  • USB C One-cable solution for audiovisual, power, and touch signal transmission
  • Flexible display setup – work at any angle
  • Compact size, light weight, and highly portable
  • Sturdy and durable design

Technical Specifications

  • Display
    • Display Size (in.): 16
    • Viewable Area (in.): 15.6
    • Panel Type: IPS Technology
    • Resolution: 1920 x 1080
    • Resolution Type: FHD (Full HD)
    • Static Contrast Ratio: 800:1 (typ)
    • Dynamic Contrast Ratio: 50M:1
    • Light Source: LED
    • Brightness: 250 cd/m² (typ)
    • Colors: 262K
    • Color Space Support: 6 bit true
    • Aspect Ratio: 16:9
    • Response Time (Typical GTG): 6.5ms
    • Response Time (GTG w/OD): 6.599ms
    • Response Time (Typical Tr+Tf): 30ms
    • Viewing Angles: 178º horizontal, 178º vertical, CR>5; 170º horizontal, 170º vertical, CR>10
    • Backlight Life (Hours): 15000 Hrs (Min)
    • Curvature: Flat
    • Refresh Rate (Hz): 60
    • Blue Light Filter: Yes
    • Color Gamut: NTSC: 45% size (Typ)
    • sRGB: 64% size (Typ)
    • Pixel Size: 0.179 mm (H) x 0.179 mm (V)
    • Touch Screen: Projected Capacitive, 10-point multi-touch
    • Surface Treatment: Glossy w/ anti-finger print, Hard Coating (≧6H)
    • Cover Glass Thickness: 0.8mm
  • Compatibility
    • PC Resolution (max): 1920x1080
    • Mac® Resolution (max): 1920x1080
    • PC Operating System: Windows 10/11 certified; macOS tested
    • Mac® Resolution (min): 1920x1080
  • Connector
    • USB 3.2 Type C Up Stream; DisplayPort Alt mode : 2 (60W power charger)
    • 3.5mm Audio Out: 1
    • Mini HDMI: 1
    • Power in: USB Type C (with video & data)
  • Audio
    • Internal Speakers: 0.8Watts x2
  • Power
    • Eco Mode (Conserve): 6W
    • Eco Mode (optimized): 6.9W
    • Consumption (typical): 8W
    • Consumption (max): 8.3W
    • Voltage: AC 100-240V
    • Stand-by: 0.5W
    • Power Supply: External Power Adaptor
  • Controls
    • Physical Controls: Up, Right, Down, Left, Power
    • On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
  • Operating Conditions
    • Temperature: 32°F to 104°F (0°C to 40°C)
    • Humidity (non-condensing): 20% to 90%
  • Input Signal
    • Frequency Horizontal: 15 ~ 82KHz
    • Frequency Vertical: 50 ~ 75Hz
  • Video Input
    • Digital Sync: TMDS - mini HDMI (v1.4), Micro-Packet - Type C
  • Ergonomics
    • Tilt (Forward/Back): 20º / 60º
  • Weight (imperial)
    • Net (lbs): 2.1
    • Net Without Stand (lbs): 2.1
    • Gross (lbs): 5.1
  • Weight (metric)
    • Net (kg): 0.96
    • Net Without Stand (kg): 0.96
    • Gross (kg): 2.3
  • Dimensions (imperial) (wxhxd)
    • Packaging (in.): 17.3 x 11.3 x 3.5
    • Physical (in.): 14 x 8.8 x 0.6
    • Physical Without Stand (in.): 14 x 8.8 x 0.6
  • Dimensions (metric) (wxhxd)
    • Packaging (mm): 440 x 288 x 89
    • Physical (mm): 355 x 223 x 16
    • Physical Without Stand (mm): 355 x 223 x 16
  • General
    • Regulations: cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, NRCan, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, RCM, GEMS, VCCI, PSE, BIS
    • PACKAGE CONTENTS: TD1655 x1, mini HDMI to HDMI Cable (v1.4; Male-Male) x1, USB Type-C Cable (Male-Male) x1, USB Type-C to Type-A 3.2 Gen1 Cable (Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1, Protect cover x1, Clean cloth x1, Passive touch pen x1
    • Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
    • Warranty: *Warranty offered may differ from market to market
    • Power Management: Energy Star standards, EPEAT
Resolution:
Full HD (1920 x 1080)
Screen Size:
16"
