Viewsonic LS560WE 3200lms WXGA Short Throw LED Business/Education Projector
ViewSonicPricing available upon request
ViewSonic Projectors (unless otherwise specified) are warranted for three (3) years from the date of first consumer purchase for parts and labor and one (1) year limited lamp warranty.
The LS560WE is ViewSonic’s lamp-free high brightness WXGA short throw projector for business and education. Adopting industry-leading 3rd generation LED technology, the LS560WE delivers 3,200 ANSI Lumens while eliminating the use of toxic mercury, reducing the cost and effort of frequent lamp replacement and lowering the total cost of ownership. The lamp-free light source offers enhanced sustainability for a greener environment while delivering a wider color gamut for bright and vivid images in a meeting room, classroom, or any other environment. The 0.49 short throw lens provides a 100” screen from just 1.1m away, delivering exceptional space efficiency and freeing presenters from blinding lights. The projector boasts incredible ease of use with instant power on/off, easy image correction with H/V keystone and 4 corner adjustment, and 360° tilt angle projection for flexible applications. Moreover, its comprehensive LAN control makes multiple device management a breeze and is compatible with Crestron, AMX, Extron, PJ Link, ATEN, and ViewSonic’s vController.
3rd Generation LED Technology for Greater Sustainability
With the 3rd generation LED technology, the LS560WE frees users from frequent lamp replacement and toxic mercury. Offering consistently impressive brightness for 30,000 hours, the projector saves the cost of time, manpower and money for maintenance, while providing a greener and more sustainable future.Lamp-free, Mercury-free, Maintenance-free
Saving More with the Advanced LED Technology
Adopting ams OSRAM’s Ostar Projection Power LED technology, the LED projector is both energy saving and cost efficient, consuming less energy than competing lamp-based projectors.Less Power Consumption
Enhanced Brightness for Business/Education Environments
Thanks to the latest LED technology, the LS560WE achieves a major brightness breakthrough to 3,200 ANSI Lumens. With extreme-high contrast ratio of 3,000,000:1, the projector ensures bright and detailed images in dim or lit environments.3,200 ANSI Lumens
Present the Best with Vibrant Colors
Impress any audience with ViewSonic’s exclusive color technology, covering wide color gamut, elevating your presentation with a true-to-life color experience.
Big Screen Fits for Small Spaces
The LS560WE's 0.49 short throw projection gives you 100” large screen from only 1.1m away when positioning the projector. Presenters will stay clear of the projector beam, eliminating eye glare and shadows on the projection screen.0.49 Short Throw
Effortless Image Adjustment
Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.H/V Keystone, 4 Corner Adjustment
Efficient Instant Power On/Off
Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.
Versatile Application
The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or floors.360° Projection
Centralized Control for Management Efficiency
The LS560WE is compatible with Crestron, AMX, PJ Link, ATEN and Extron systems and comes equipped with ViewSonic vController, an easy-to-use network management tool.Comprehensive LAN Control
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily and onsite via USB cable connection with your laptop.Learn more: https://youtu.be/irlhJLpDHas
*The latest projector software update can be found in the download section at the bottom of the page when available.
USB Type A Power Supply
The built-in 5V/2A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming multimedia content.
Non-stop 24/7 Operation
The advanced cooling design enables 24/7 operation without degradation of image quality or work performance, making the projector ideal for applications that require continuous use.
Sealed Optical Engine with IP5X
Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.IP5X
Dimension & I/O Ports
- LED Indicator
- Keypad
- Power Button
- Focus Ring
- Front IR
- Lens
- Audio Out
- Audio In
- HDMI
- USB-A (5V/2A, Service)
- Computer In
- Monitor Out
- RS232
- RJ45 (LAN Control)
Key Features
- 3rd generation LED technology for greater sustainability
- Maintenance free: 30,000-hour light source life and less power consumption
- 3,200 ANSI Lumens offering bright images in any environment
- 0.49 short throw ratio for glare-free and shadow-free presentations
- Ease of use: instant power on/off, H/V keystone, and LAN control
Technical Specifications
- Specifications
- Native Resolution: 1280x800
- Brightness: 3200 (ANSI Lumens)
- Contrast Ratio: 3000000:1
- Display Color: 1.07 Billion Colors
- Light Source Type: LED
- Light Source Life (hours) with Normal Mode: 30000
- Lens: F=2.6, f=6.9mm
- Projection Offset: 110%+/-5%
- Throw Ratio: 0.49
- Optical Zoom: Fixed
- Digital Zoom: 0.8x-2.0x
- Image Size: 60"-300"
- Throw Distance: 0.63m-1.58m
- (87"@0.92m)
- Keystone: H:+/-40° , V:+/-40°
- Audible Noise (Normal): 34dB
- Audible Noise (Eco): 28dB
- Input Lag: 16ms
- Resolution Support: VGA(640 x 480) to FullHD(1920 x 1080)
- HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
- Horizontal Frequency: 15K-102KHz
- Vertical Scan Rate: 23-120Hz
- Interactive Camera: Optional (vTouch-10s)
- Input
- Computer in (share with component): 1
- HDMI: 1
- (HDMI 1.4/ HDCP 1.4)
- Audio-in (3.5mm): 1
- Output
- Monitor out: 1
- Audio-out (3.5mm): 1
- Speaker: 2W
- USB Type A (Power): 1 (5V/2A)
-
Control
-
RS232 (DB 9-pin male): 1
-
RJ45 (LAN control): 1
-
USB Type A (Services): 1
-
(share with USB A Output)
-
-
Others
-
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz (AC in)
-
Power Consumption: Normal: 229W
-
Standby: <0.5W
-
Operating Temperature: 0~40℃
-
Carton: Brown
-
Net Weight: 2.85kg
-
Gross Weight: 4.05kg
-
Dimensions (WxDxH) with Adjustment Foot: 293x221x115mm
-
Packing Dimensions: 365x300x188mm
-
OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, Hungarian. Total 24 languages
-
User Guide Language: English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages
-
-
Standard Accessory
-
Power Cord: 1
-
Remote Control: 1
-
QSG: Yes
-
Lens Cover: Yes
-
Warranty Card: Yes (CN Only)
-
- Optional Accessory
- Wall/Ceiling Mount: PJ-WMK-305
- PJ-WMK-007
- Carry Bag: PJ-CASE-008
- ANSI (Lumens):
- 3200
- Resolution:
- WXGA (1280 x 800)
- Product Type:
- Projector
