Verkada CP63 Outdoor PTZ Camera, 4K, 2TB of Storage

The CP63-E 4K PTZ camera includes a large 1 / 1.8” progressive CMOS image sensor for superior image quality and precise, detailed monitoring. The CP63-E’s advanced varifocal lens with 32x motorized optical zoom and 100-meter IR range complement its Sentry Mode for unparalleled, automated monitoring of individuals across an expansive field of view. With its onboard CV72S Ambarella processor delivering advanced analytics like AI-powered search, AI-powered alerts, Person of Interest detection, and crowd detection, the CP63-E excels in monitoring large areas such as sports fields, parking lots, or stadiums

Installation Guide (Click Here)

Key Features

• Maximum 60 Days of Retention
• Superior image quality

  • Large 1 / 1.8” progressive CMOS image sensor
  • 4K resolution
  • Varifocal lens with 32x optical zoom
  • 100 meters / 328 feet of IR range for long-range nighttime viewing
• Advanced analytics

  • Onboard CV72S Ambarella processor enables people and vehicle analytics
  • AI-powered search and AI-powered alerts
• Automated monitoring

  • Support Sentry Mode with up to three context cameras for automated monitoring of vast areas
• Hybrid cloud architecture

  • Onboard storage and processing helps reduce bandwidth consumption, enabling coverage at scale
  • 30 - 90 days (1TB - 3TB) of onboard storage
  • Redundant cloud backup and unlimited cloud-based archiving of footage monitoring
• Durability and weather protection

  • Robust metal housing
  • IP66 weather rating
  • IK10 impact rating
  • Operability between -40°C to 50°C / -40°F to 122°F

Technical Specifications

• Camera
  • Image Sensor: 1 / 1.8” Progressive CMOS
  • Sensor Resolution: 4K (3840 x 2160)
  • Lens Type: Varifocal; motorized zoom
  • Focal Length: 6.5mm – 212mm
  • Aperture: F1.4 – F4.9
  • Iris: P-Iris
  • Field of View

    • Horizontal: 64° - 2°
    • Vertical: 37° - 1°
    • Diagonal: 71° - 2°
  • Sensor Movement:
    • Tilt: 220°
    • Pan: 360°
  • Shutter Speed: 1 / 30 sec. to 1 / 10,000 sec.
  • Day/Night: IR-cut filter for day and night function
  • IR Cut Filter: Yes
  • IR Range: 100m / 328ft
  • Minimum Illumination

    • 0.02 lux @ F1.4 (Color)
    • 0 lux @ F1.4 with IR Illuminators on
  • Onboard Storage

    • Capacity: From 1TB to 3TB
    • Card: MicroSD, SDXC
  • CPU: Ambarella CV72S66
• Standard video settings
  • Compression: H.265 (historical video only), H.264
  • Frame Rate: 24fps
  • Live Streaming Settings (Per Head)

    • Static: 1,000 Kbps (SQ), 3,000 Kbps (HQ)
    • Moving: 2,000 Kbps (SQ), 4,500 Kbps (HQ)
  • Historical Video Settings: Adaptive quality
  • WDR Technology: True WDR, dual exposure
• Standard audio settings
  • Audio: Not supported
• Power and network
  • Power Input

    • With IR: IEEE 802.3bt Type 3 PoE++
    • Without IR: IEEE 802.3bt Type 3 PoE++
    • Extended temperature range: IEEE 802.3bt Type 3 PoE++
  • Power Consumption

    • With IR: 42.5 - 57.0V, 1.13 - 0.85A, 48.0W
    • Without IR: 42.5 - 57.0V, 0.8 - 0.60A, 34.0W
    • Extended temperature range: 42.5 - 57.0V, 1.20 - 0.90A, 51.0W
  • Connectivity: RJ-45 cable connector for network/PoE connection; 10 / 100 Mbps
  • RTSP

    • RTSP 1.0
    • RFC 2326
    • Max concurrent streams: 2
    • Audio support: No
• General
  • Operating Temperature: -40°C to 50°C / -40°F to 122°F
  • Humidity: 0 to 90%
  • LED Indicator: System power and status indicator
• Mechanical
  • Weight

    • Camera: 7.53kg / 16.6lbs
    • Pendant cap: 0.41kg / 0.9lbs
  • Dimensions:
    • Ø: 256mm / 10.1in, H: 406mm / 16.0in with pendant cap
    • Ø: 256mm / 10.1in, H: 336mm / 13.2in without pendant cap
  • Body: Aluminum, plastic, glass
• Software capabilities
  • Alerts: Camera status, motion detection, people detection, vehicle detection, Person of Interest detection, crowd detection, AI-powered alerts
  • Streaming and storage: Cloud backup, configurable retention days, selectable storage location, low bandwidth mode, timelapse, RTSP, footage archive
  • People analytics: People search, attribute search, face search, Sentry Mode, motion search, trajectory analysis, selective face blurring, AI-powered search
  • Sharing and privacy: Live Links, audit log
  • Vehicle analytics: Vehicle search, attribute search, motion search, trajectory analysis, AI-powered search
  • Controllers: Mouse, keyboard, Xbox Wireless Controller, joystick

What's Included

• CP63 Camera
• Rubber cap
• Pendant cap
• T30 security L-wrench
