Tascam Professional CD Player with SD/USB Media

Direct access to 10 user defined folders configured within SD/SDHC and USB media

The number keys on the front panel can be used not only to select tracks on a CD but also for direct access to user-defined folders that you select on SD/SDHC cards and USB memory drives. By setting up individual folders like single albums, you can choose folders on solid-state media just like you would choose albums with a CD changer. Assigning folders is easy.

• Step1：Press to the [BROWSE] key to enter browse mode.
• Step2：Use the [FOLDER] keys to select the folder you want.
• Step3：Press the [SET] key and then press a number key to assign the folder to it.

Transfer audio from CDs to SD/SDHC cards and USB memory drives straight from the device

The CD-200SB can convert audio CDs into files by itself. This two-step procedure is simple. Since CD audio is converted into files as the disc plays back, file conversion will be completed as you listen.

• Step1：Load the CD and the SD/SDHC card or USB flash drive, and press the [DUBBING] button.
• Step2：Use the number keys to select the folder that you want to dub to. If there is no folder, one will be created automatically. After doing this, dubbing will start automatically. When the CD playback stops, file conversion will be complete.

Solid-state media - reliable durable and versatile

The CD-200SB can use SD/SDHC cards and USB memory drives as playback sources. Due to the removal of rotation mechanisms, solid-state media is highly durable and reliable. For installed sound applications where solid state media is used heavily, the CD-200SB offers versatility that no other player does.

Key Features

• SD/SDHC, USB playback
• Direct access to 10 user defined folders configured within SD/SDHC and USB media
• Dubbing from CD to memory storages (WAV or MP3)
• Playback format:
  CD: CD-DA, WAV, MP3, MP2
  SD/SDHC, USB: WAV, MP3, MP2, WMA, AAC
• CD Text and ID3/WMA/AAC tag display
• Four playback modes: continuous, shuffle, single and program
• Repeat playback modes
• Folder repeat playback mode for data CDs, SD/SDHC and USB
• Various time display (CD-DA: Track elapsed, track remain, total remain   others: Elapsed)
• +/- 14.0 % pitch control for CD
• Intro check
• Shock-proof memory (up to 10 sec)
• RCA unbalanced output
• XLR balanced output
• RCA analog unbalanced output, RCA coaxial and Optical digital outputs
• EIA 2 U Rack mount size
• Wireless Remote controller included
• Headphone Output (1/4”)
• ROHS Certified

Technical Specifications

• Playback media: SD/SDHC card、USB flash-drive、CD-DA、CD-R、CD-RW
• Playback format
  • WAV (Data CD, SD/SDHC, USB): Stereo, 8kHZ – 48kHz、8/16bit
  • MP3 (Data CD, SD/SDHC, USB): Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz、8 - 320kbps、VBR
  • CD-DA: Stereo, 44.1kHz、16bit
  • MP2 (Data CD, SD/SDHC, USB): Stereo, 16/32/22.05/44.1/24/48kHz、8 - 384kbps、VBR
  • WMA(SD/SDHC, USB): Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz、8-320kbps, VBR
  • AAC(SD/SDHC, USB): Stereo,
  • 8/16/32/11.025/22.05/44.1/12/24/48kHz、8 - 320kbps、VBR
• Number of channels: 2 channel (stereo)
• Recording format:
  • WAV: 44.1kHz, 16bit
  • MP3: 44.1/48kHz, 64/128/256kbps
• ANALOG OUT
  • unbalanced: RCA
    • Nominal output level: -10dBV
    • Maximum output level: +6dBV
    • Output impedance: 200Ω
  • balanced: XLR-3-32（1:GND、2:HOT、3:COLD）
    • Nominal output level: +4dBu
    • Maximum output level: +20dBu
    • Output impedance: 200Ω
  • PHONES OUT: 6.3mm(1/4") stereo phone jack
    • Maximum output level: 20mW + 20mW (THD 0.1%, 32Ω loaded)
• DIGITAL OUT
  • COAXIAL: RCA
    • Output impedance: 75Ω
    • Compatible signal format: IEC60958-3 (S/PDIF)
  • OPTICAL: TOS (JEITA RC-5720C)
    • Compatible signal format: IEC60958-3 (S/PDIF)
• Power source :US, Canada:120V AC, 60Hz / EUR:230V AC, 50Hz / Australia:240V AC, 50Hz
• Power consumption: 11W
• Size (W x H x D)mm: 481 x 94.5 x 298
• Weight: 4.7kg
• Audio performance
  • Frequency response: 20Hz – 20kHz, +/-1.5dB (playback, JEITA)
  • THD: Less than 0.01% (playback, JEITA)
  • S/N ratio: 90dB or greater (playback, JEITA)
  • Dynamic range: 990dB or greater (playback, JEITA)
  • Channel separation: 90dB or greater (playback, JEITA)
