Sennheiser TeamConnect Ceiling 2 with Microphone Array (White)

Sennheiser TeamConnect Ceiling 2 with Microphone Array (White)

Sennheiser
SKU:
507488

Pricing available upon request

2 Years Warranty
Current Stock:
Description

The TeamConnect SL Ceiling 2 Microphone Array from Sennheiser is designed to provide better audio quality for voice and video conferences. It features adaptive beamforming technology that automatically follows the active speaker's voice, letting people speak naturally whether they are sitting, standing, or walking around the room.

TeamConnect Ceiling 2 offers great versatility and interoperability with support for Dante networks and POE (Power over Ethernet). It is compatible with Sennheiser's Control Cockpit software for efficient remote management and offers remote configuration and monitoring via an open media control protocol (API), allowing for easy integration into media systems. A 3-pin Phoenix connector and eight self-adhesive rubber feet are also included.

  • Ceiling microphone array with patented automatic speaker position detection and dynamic beamforming for best speech intelligibility
  • Analog and digital (Dante) audio outputs for easy connectivity to video and audio conference systems
  • Configuration and monitoring via Sennheiser´s Control Cockpit software
  • Open API for media and camera control applications
  • Several installation options via suspension kit, flush mount or surface bracket (sold separately)
Key Features
  • For Fixed Conference Installations
  • 28 Sennheiser KE 10-237 Mic Capsules
  • Automatic Beamforming Technology
  • Focuses on Whoever Is Speaking in Room
  • 2 x Dante Interface with RJ 45 Outputs
  • 3-Pin Terminal for Analog Audio Output
  • RJ 45 Ethernet for Network Control
  • Sennheiser Control Cockpit Software
  • Includes a 3-Pin Phoenix Connector
  • 8 x Self-Adhesive Rubber Feet

Technical Specificaitons

  • Audio Output:
    • 1 x 3-Pin Terminal (Fits Phoenix Contact MCVW 1.5-3-ST-3.81)
    • 2 x Digital Dante Network Audio
    • (RJ-45 Primary and Secondary)
  • Ethernet Control: 1 x RJ-45 Ethernet Port for PoE Power Supply and Data/Control Communication
  • Supply Voltage:
    • 44 to 57 VDC
    • PoE IEEE 802.3af Class 3
  • Power Consumption: Maximum 8.8 W
  • Plenum Rating: Tested According to UL 2043
  • Transducer Principle: Pre-Polarized Condenser Microphone
  • AF Frequency Response: 160 Hz to 18 kHz
  • Sensitivity: 0 dBV/Pa (988 mV/Pa)
  • Signal to Noise Ratio: 83 dB (A)
  • Latency: 4 ms
  • Equivalent Noise Level: 11 dB (A)
  • Polar Pattern (Microphone): 28 Capsules
  • Pick Up Pattern: Beam Pattern
  • Max Sound Pressure: 104 dB SPL
  • Dynamic Range: 93 dB (A)
  • Temperature:
    • Operation: 32 to 104°F / 0 to 40°C
    • Storage: 14 to 140°F / -10 to 60°C
  • Humidity (Relative): 20 to 95% Non-Condensing
  • Dimensions: 23.2 x 23.2 x 1.7" / 59 x 59 x 4.3 cm
  • Weight: 12.5 lb / 5.7 kg

What's Included

  • Sennheiser TeamConnect SL Ceiling 2 Microphone Array
  • 3-Pin Phoenix Connector
  • 8 x Self-Adhesive Rubber Feet
  • Limited 2-Year Manufacturer Warranty
Additional Information
Meeting Room Size:
Medium
Meeting Room Size:
Large
Product Type:
Video Conferencing
Meeting Room Size:
Small
