Sennheiser SL PASC 2 Two-Channel Passive Antenna Splitter/Combiner for SpeechLine Series

Sennheiser SL PASC 2 Two-Channel Passive Antenna Splitter/Combiner for SpeechLine Series

Sennheiser
SKU:
390040

Pricing available upon request

2 Years Warranty
Current Stock:
Description

The SL PASC 2 is a passive 2-way Diversity antenna splitter/combiner for the SpeechLine Digital Wireless microphone series.

The SL PASC 2 is a passive 2-way Diversity antenna splitter / combiner for the SpeechLine Digital Wireless microphone series. It is used to distribute the antenna signals of up to 2 SpeechLine Digital Wireless links. This reduces the number of required antenna cables to a minimum when the AWM 2 or AWM 4 remote antennas are used. The rack receivers are connected to the SL PASC 2 using the supplied SMA-R cables.

Key Features
  • 1880 - 1930 MHz (DECT range)
  • 4 RF outputs for connecting up to 2 SL Rack Receiver DW units
  • 2 RF inputs to connect AWM 2 or AWM 4
  • RP-SMA connectors
  • Passive antenna combiner / splitter

Technical Specificaitons

  • Type: 2-Channel, Connects to a maximum of Two Receivers
  • Frequency Band: DECT: 1880 to 1930 MHz
  • Connectors: 6 x RP-SMA (AC-Coupled)
  • Attenuation: 4.5 dB Typ.
  • Input Power: 1.5 W, Max
  • Color: Black
  • Operating Temperature: -40 to 185°F / -40 to 85°C
  • Dimensions: 5.9 x 2.0 x 0.8" / 150.0 x 50.0 x 21.0 mm
  • Weight: 4.8 oz / 135.0 g

What's Included

  • SL PASC 2
  • 4x SMA-RP cable (50 cm)
  • Quick guide
  • Safety guide
Additional Information
Product Type:
Microphone
