Samsung LH85OHNSLGB/XS 85" OH85N-S Outdoor Signage Display

Samsung
SKU:
LH85OHNSLGB/XS

Pricing available upon request

Samsung 3 year(s) limited warranty against manufacturer defects. During the warranty period, the manufacturer's appointed authorised service centre will, at its sole discretion (a) repair the product using new or refurbished parts, (b) replace the product with a new or refurbished product.
Current Stock:
Description

Large displays optimized for DOOH

The OHN series has elevated the typical outdoor advertising experience with its bold and engaging content delivery for any bus stop or street billboard. The OHN series will make any business standout from the crowd with its immersive and high-quality images and content.

Large displays optimized for DOOH

Unsurpassable visibility day and night

The OHN series allows for exceptional, consistent content delivery with 3,000nit brightness and 24/7 performance. With a built-in dimming sensor, the display automatically adjusts the brightness based on the external lighting environment, saving display operating expenses and power consumption.

Unsurpassable visibility day and night

Easy-to-use management software

The embedded MagicINFO Player S6, backed by the powerful TIZEN operating system, boosts the display’s overall performance, allows for painless content management and ensures seamless transition and playback.

Easy-to-use management software

Built strong to endure impacts

The OHN series provides advanced safety through tempered Magic Protection Glass. It features durability that is IK10-rated, further proving its robust level of strength that can endure physical impact.

Built strong to endure impacts

Resistant to outdoor elements

The OHN series is verified to perform in outdoor settings – with IP56-rated protection ensuring that the OHN series will withstand physical impact as well as dust, humidity or other outdoor elements that could affect the display.

Resistant to outdoor elements

Key Features

  • Unsurpassable visibility day and night
  • Easy-to-use management software
  • Built strong to endure impacts

Technical Specifications

  • Display
    • Diagonal Size: 85"
    • Panel Type: VA
    • Resolution: 3,840 x 2,160
    • Pixel Pitch (HxV): 0.4875(H) x 0.4875(V)
    • Brightness (Typ): 3,000nit
    • Contrast Ratio: 3,000:1
    • Viewing Angle (H/V): 178/178
    • Response Time: 8ms
    • Colour Gamut: 72 %
    • Glass Haze: 0 %
    • H-Scanning Frequency: 15~135KHz (HDMI), 30~135KHz (DP)
    • Maximum Pixel Frequency: 594MHz (HDMI), 533.25MHz(DP)
    • V-Scanning Frequency: 24~75Hz (HDMI), 30~75Hz (DP)
    • Contrast Ratio (Dynamic): 100,000:1
  • Connectivity
    • HDMI In: 2
    • DP In: 1
    • Version of HDMI: 2
    • Version of DP: 1.2
    • Version of HDCP: 2.2
    • USB: 1
    • Audio Out: Stereo Mini Jack
    • RS232 In: Stereo Mini Jack
    • RJ45 In: Yes
  • Power
    • Power Supply: AC100-240V 50/60Hz
    • Power Consumption (On Mode): 1800 W
    • Power Consumption (Sleep Mode): 0.5 W
  • Dimensions
    • Set Dimension (WxHxD): 2004 x 1185 x 120 mm
    • Package Dimension (WxHxD): 2175 x 1383 x 495 mm
  • Weight
    • Set Weight: 163 kg
    • Package Weight: 185 kg
  • Operation Conditions
    • Temperature: -30℃~50℃
    • Humidity: 10 ~ 80%, non-condensing
  • Mechanical Specification
    • Bezel Width: 62
    • Glass Thickness: 5T
    • Glass Film: AR, λ/4
  • Optional Feature
    • Protection Glass: Yes
    • Mount: No
    • Stand: No
  • SoC
    • OS Version: Tizen 4.0
    • Flash Memory Size: 8GB
  • Internal Player (MagicInfo)
    • MagicInfo Daisychain Videowall Support: No
  • Certification and Compliance
    • EMC: FCC (USA) Part 15, Subpart B Class B
    • Safety:
      • CB (Europe) : IEC60950-1/EN60950-1 CCC
      • (China) : GB4943.1-2011 PSB
      • (Singapore ) : PSB+IEC60950-1 NOM
      • (Mexico ) : NOM-001-SCFI-1993 IRAM
      • (Argentina ) : IRAM+IEC60950-1 SASO
      • (Saudi Arabia ) : SASO+IEC60950-1 BIS
      • (India) : IEC60950-1 / IS13252 NOM
      • (Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998 KC
      • (Korea) : K 60950-1 EAC
      • (Russia) : EAC+IEC60950-1 INMETRO
      • (Brazil) : INMETRO+IEC60950-1 BSMI
      • (Taiwan) : BSMI+IEC60950-1 RCM
      • (Australia) : IEC60950-1/AS/NZS 60950-1 UL
      • (USA) : cUL60950-1 CSA
      • (Canada) : cUL TUV
      • (Germany) : CE NEMKO (Norway) : CE
Additional Information
Resolution:
Ultra HD - 4K
Screen Size:
85"
Product Type:
Display
Brightness:
3000nit
