Q-SYS NV-32-H Network Video Endpoints

The NV-32-H (Core Capable) is a multipurpose, software-configurable video endpoint native to the Q-SYS Platform, offering two distinct operating modes to choose between, based on the needs of the application. ‘Core Mode’ transforms the device into a fully integrated Q-SYS processor with local HDMI switching capabilities. ‘Peripheral Mode’ allows multi-stream video encoding or decoding for network-based HDMI video distribution. Like all Q-SYS devices, the NV-32-H (Core Capable) offers native integration and control driven by the Q-SYS OS, simplifying setup and configuration while eliminating the need for advanced programming knowledge. With its Q-SYS Platform integration, you’re able to receive cryptographically-signed firmware updates, ensuring secure updates in functionality and security to your entire system.

Core Mode

Meeting Room

Small Classroom

Core Mode + Streaming

Meeting Room

Lecture Hall

Peripheral Mode

Large Meeting Room

Lecture Hall

Key Features

• Core Mode
  • True Q-SYS processing and I/O capabilities
    Complete audio processing for the Q-SYS Platform. Includes 32x32 network audio channels, eight software-based acoustic echo cancelation (AEC) channels and onboard audio via HDMI, USB and 3.5mm connections. Optional software feature licenses include a robust control engine, UCI creation and deployment, Dante audio channels and Q-SYS Shift™ encoding or decoding.
  • Integrated video capabilities
    Core Mode enables an onboard 3x2 HDMI video switcher, allowing in-room users to share content from their laptops or other devices easily. The Core Mode Video Streaming feature license enables encoding or decoding via Q-SYS Shift™.
  • Integrated AV Bridging
    Seamlessly connect Q-SYS network camera and audio feeds via a driverless USB connection into all major UC&C conferencing applications, including Microsoft Teams, Zoom and Google Meet.
• Peripheral Mode
  • Native video distribution for the Q-SYS Platform:
    Native HDMI audio and video distribution without additional control processors or complicated programming.
  • Optimized for the connected meeting space:
    Q-SYS Shift® video codec dynamically adjusts network bandwidth based on video content, delivering the right balance of quality, latency and network efficiency for meeting room video applications.
  • Integrated AV Bridging:
    Seamlessly connect Q-SYS network camera and audio feeds via a driverless USB connection into all major UC&C conferencing applications, including Microsoft Teams, Zoom and Google Meet.

Technical Specifications

• Channel Capacity (Core Mode only)

  • Q-LAN / AES67: 64 x 32
  • Dante Channels: licensable up to 32 x 32 (none included)
  • AEC processors: 8
  • VoIP instances: 1
  • Audio recording / playback: 4 ch recording / 16 ch playback
  • Q-SYS NM-T1 capacity: 3
• Encoding/Decoding (Peripheral Mode only)

  • Video compression: Q-SYS Shift™ compression codec
  • Bitrates: 10 Mbps - 800 Mbps
  • Content protection: HDCP 2.2 compliant, AES-128 encryption for all audio and video signals between encoders and decoders
• Audio I/O

  • HDMI inputs: 8-channel PCM audio, Q-SYS routable
  • HDMI outputs: 8-channel PCM audio, Q-SYS routable
  • Analog input: 3.5 mm unbalanced stereo mic/line input
    Q-SYS routable
  • Analog output: 3.5 mm unbalanced stereo line output
    Q-SYS routable
• Video I/O

  • HDMI 2.0 inputs: 3x HDMI capable of receiving source input video formats up to 4K60 4:4:4
    HDMI 2.0 outputs: 2x HDMI capable of scaling and outputting video formats up to 4K60 4:4:4
    Scaler: Each HDMI output features a robust 4K60 4:4:4 scaler that can accommodate the most challenging resolution and frame rate conversions
• Connectors

  • RS-232: Three-pin Euroblock terminal connector for extension of Q-SYS control to third-party devices, user configurable
  • GPIO: Euroblock terminal connector for extension of Q-SYS control to third-party devices, user configurable
  • LAN A: Gigabit LAN connection for interfacing with Q-LAN. PoE 802.3bt Type 4 for power.
  • LAN B: Redundant connection for audio & control traffic (Core Mode only)
  • Audio input:
    • Signal to Noise: 90 dBFS
    • THD+N: 0.009% @ 0 dB
  • Audio output:
    • Signal to Noise: 90 dBFS
    • THD+N: 0.0167% @ 0 dB
• Power

  • Power over Ethernet specification/wattage: Conforms to IEEE 802.3bt Type 4
  • Physical power supply info: 48 V DC Nominal, 1.5 A on 2-pin Euro connector
• Environmental

  • Ambient operating temperature range: 0-50° C
  • Humidity: 5 to 85% non-condensing
  • Storage temperature: -20 to 70° C
• General

  • Dimensions:
    • 8.66 in x 11.28 in x 1.72 in
    • 220 mm x 286.6 mm x 43.6 mm
  • Weight: 4.0 lb (1.81 kg)
  • Regulatory compliance CE, FCC Part 15 Class B, RoHS
  • Mounting options:
    • Rack-mountable, 1RU half-rack width
    • Surface-mountable, table or wall-mount
    • All mounting hardware is included
