Q-SYS NL-SB42 Network Loudspeaker

Q-SYS
SKU:
NL-SB42

Pricing available upon request

Current Stock:

The Q-SYS NL-SB42 is a network PoE soundbar that delivers clear speech and music reproduction natively to Q-SYS. It features a two-way design that provides wide off-axis response, and is optimized to better handle program content (in addition to voice content). The Q-SYS NL-SB42 supports vertical or horizontal mounting and can be integrated into your space with a single Ethernet cable to reduce overall hardware footprint and lower system cost. As a native Q-SYS Product, you can take advantage of the drag-and-drop integration and simple control capabilities offered by Q-SYS.

Two-way network PoE soundbar: The Q-SYS NL-SB42 is a two-way PoE soundbar that features a 4-inch woofer and 0.75-inch tweeter, and supports both horizontal and vertical mounting. The two-way design enables a wide off-axis response, and is primed to better handle program and voice content, making it a great option for any high-value space.

In Sync with Q-SYS Call Sync: The Q-SYS NL-SB42 network soundbar features a fully configurable LED status indicator. This LED can also be controlled automatically by Q-SYS Call Sync, which syncs onboard controls and LED status indicators on select Q-SYS device (NM-T1 microphone, TSC Series Gen 3 touchscreens & NL-SB42 PoE soundbar) keeping the state of all in-room endpoints in sync. Additionally, Q-SYS Call Sync provides mute sync for UC platforms via the Q-SYS HID controller, as well as ringing and hook state for Q-SYS softphone and POTS controller.


alt_text



Mix and Match: NL Series network loudspeakers are built on the same design principles as the Q-SYS AcousticDesign™ Series, featuring a sleek, unobtrusive design along with the same sonic characteristics that allow integrators to mix-and-match form factors to fit the unique needs of any space.

Go Easy: NL Series network loudspeakers are powered-over-Ethernet (PoE), which means native Q-SYS audio data, power and control and are delivered over a single cable, greatly simplifying installation and deployment while reducing rack space requirements.

Image of someone plugging in ethernet to NL-SB42

Intrinsic Correction: Q-SYS automatically integrates loudspeaker voicings (Intrinsic Correction) to simplify the tuning process.

Remote Monitoring and Management: NL Series network loudspeakers are the first loudspeakers that can be automatically monitored and managed by Q-SYS Reflect Enterprise Manager every step of the way, from the audio source all the way through the loudspeaker driver.

Designed for Q-SYS: Q-SYS NL Series PoE loudspeakers are native to Q-SYS, a cloud-manageable audio, video and control platform, built to deliver scalable, flexible AV solutions into the future.

Meeting Room

Diagram of a meeting room utilizing Q-SYS hardware including the NM-TI microphone

Meeting Room with Centralized Processing

Diagram of 4 meeting rooms utilizing Q-SYS hardware including the NM-TI microphone, all with centralized processing connecting the 4 rooms.

Key Features

  • Native PoE soundbar for Q-SYS
  • 3.5-inch woofer + 0.75-inch tweeter
  • Two-way design provides wider off-axis response optimized for program and voice content
  • Supports vertical and horizontal mounting
  • Powered-over-Ethernet enables power, data, and control over a single cable
  • Programmable RGB light bar
  • Consistent tonal characteristics across the entire NL Series family to let you mix and match form factors
  • Q-SYS integrates loudspeaker voicings (Intrinsic Correction) to simplify the tuning process
  • Comprehensive management via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager
  • Includes quick-install wall bracket, with 3 cm of fine adjustment

Technical Specifications

  • Loudspeaker type: Network PoE soundbar for Q-SYS
  • LF transducer: 3.5-in (88.9 mm) paper cone woofer
  • HF transducer: 0.75-in (19.05 mm) silk dome tweeter
  • Effective frequency range: 110 Hz - 20 kHz
  • Rated noise power: 12 W (PoE), 24 W (PoE+)
  • Rated coverage: 150° horizontal, 160° vertical (1 kHz - 10 kHz)
  • Directivity factor: 2.7
  • Directivity index: 4.2 dB
  • Maximum continuous SPL: 90 dB (PoE), 93 dB (PoE +)
  • Maximum peak SPL: 106 dB (PoE), 107 dB (PoE +)
  • Input connector type: RJ45
  • Power requirements: PoE (Type 1 Class 3) or PoE+ (Type 2 Class 4)
  • Enclosure material: ABS
  • Grille material: Powder-coated steel
  • Operating temperature range: 10° to 40° C (50° to 104° F)
  • Net weight: 3.86 lbs (1.75 kg)
  • Product dimensions: 20.4 x 3.97 x 2.87 in (518.1 x 101 x 73 mm)
  • Safety agency: UL/IEC 62368-1, CE

What's Included

  • Wall-mounting bracket
  • Rubber feet
