Q-SYS NL-C4 Network Ceiling-Mount Loudspeaker

Q-SYS
SKU:
NL-C4-WH

Pricing available upon request

Current Stock:

The Q-SYS NL-C4 is a network PoE loudspeaker that delivers clear speech and music reproduction natively to Q-SYS. The ceiling-mount loudspeaker features a four-inch, full-range driver, and can be integrated into your space with a single Ethernet cable to reduce overall hardware footprint and lower system cost. As a native Q-SYS Product, you can take advantage of the drag-and-drop integration and simple control capabilities offered by Q-SYS.

Full-range ceiling-mount PoE loudspeaker: The Q-SYS NL-C4 features a 4-inch, full-range driver in a ceiling-mount enclosure that delivers both clear speech and music reproduction for any high-value collaboration space.

Mix and Match: NL Series network loudspeakers are built on the same design principles as the Q-SYS AcousticDesign™ Series, featuring a sleek, unobtrusive design along with the same sonic characteristics that allow integrators to mix-and-match form factors to fit the unique needs of any space.

Go Easy: NL Series network loudspeakers are powered-over-Ethernet (PoE), which means native Q-SYS audio data, power and control and are delivered over a single cable, greatly simplifying installation and deployment while reducing rack space requirement.

Image of someone plugging in ethernet to NL-C4

Intrinsic Correction: To simplify the tuning process, Q-SYS automatically integrates loudspeaker voicings (Intrinsic Correction™) to simplify the tuning process.

Remote Monitoring and Management: NL Series network loudspeakers are the first loudspeakers that can be automatically monitored and managed by Q-SYS Reflect Enterprise Manager every step of the way, from the audio source all the way through the loudspeaker driver.

Designed for Q-SYS: Q-SYS NL Series PoE loudspeakers are native to Q-SYS, a cloud-manageable audio, video and control platform, built to deliver scalable, flexible AV solutions into the future.

Boardroom

Diagram of a small classroom featuring Q-SYS hardware including and peripherials

Key Features

  • Native PoE ceiling-mount loudspeaker for Q-SYS
  • 4-inch, full-range driver
  • Powered-over-Ethernet enables power, data, and control over a single cable
  • Consistent tonal characteristics across the entire NL Series family to let you mix and match form factors
  • Q-SYS integrates loudspeaker voicings (Intrinsic Correction™) to simplify the tuning process
  • Comprehensive management via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager
  • Available in white (RAL 9010) only

Technical Specifications

  • Loudspeaker type: Network PoE ceiling-mount loudspeaker for Q-SYS
  • Driver: 4-in (101.6 mm) full-range, paper cone woofer, ferrite magnet
  • Effective frequency range: 100 Hz to 20 kHz
  • Rated noise power / voltage (W rms): 12 W (PoE), 24 W (PoE+)
  • Rated coverage (-6 dB): 120°
  • Directivity factor: 3.8
  • Directivity index: 5.8 dB
  • Maximum continuous SPL: 94 dB (PoE), 97 dB (PoE+)
  • Maximum peak SPL: 108 dB (PoE), 111 dB (PoE+)
  • Input connector type: RJ45, Q-LAN
  • Enclosure material: ABS baffle on powder steel back can
  • Grille material: Powder coated steel
  • Ingress protection: IP34
  • Cutout dimension: 7.1 in (179 mm) hole diameter
  • Net Weight: 3.5 lbs (1.6 kg)
  • Product dimensions (diameter x height): 8.46 x 4.13 in (215 x 105 mm)
  • Operating environment: Desgined for indoor use
  • Operating temperature range: 10° to 40° C
  • Safety agency: UL/IEC 62368-1
  • Plenum rating: UL 2043
  • Power requirements: PoE (Type 1 Class 3) or PoE+ (Type 2 Class 4)

What's Included

  • C-rings and tile rails
  • Rail screws
  • Cut-out template
  • Grille
  • Optional Accessories: NL-C179 (bezel-less collar), AD-MR4 (pre-install mud ring)
