Panasonic PT-VMZ62 6500lms WUXGA Laser LCD Projector (White)

Name: Panasonic PT-VMZ62 6500lms WUXGA Laser LCD Projector (White)
Brand: Panasonic
SKU: PT-VMZ62 - White
Price: 4940.97 SGD
Availability: InStock

Panasonic

SKU:

PT-VMZ62 - White

Pricing available upon request

Warranty: 3 Years

Enjoy clear projection tailored to your space with the Panasonic PT-VMZ62B 6500-Lumen WUXGA Projector. This compact projector utilizes a long-lasting laser light source and 3LCD color to produce vibrant visuals in well-lit spaces. It features a 1.6x optical zoom, generous lens shift, Daylight View mode, and advanced geometric correction, including corner and curved screen adjustments, making it well suited to lights-on applications including corporate, education, simulation, and more.

High Dynamic Contrast

Input signals are analyzed frame by frame to regulate light output for best contrast performance in every scene. As well as accurately reproducing pictures that contain a mix of dark and bright hues, Dynamic Contrast is energy efficient and can be optimized to suit the content or the room’s lighting. The projector’s high 5,000,000:1 dynamic contrast ratio provides better detail definition in shadows with deeper blacks, brighter whites, and more natural skin tones for a better sense of depth and definition.

Optimized Visuals for Bright Spaces

Daylight View Basic uses a sensor to measure ambient light levels in your room and adjusts sharpness, halftone color, contrast, and brightness to optimize image visibility regardless of room illumination. The result is a clearer, more detailed image, even in challenging conditions.

Digital Zoom Extender and Digital Image Shift

Digital Zoom Extender increases the projector’s throw distance beyond its optical zoom range, making it possible to reuse your existing ceiling mount or install the projector farther from the screen, saving construction work. Digital Image Shift allows the image to move up to 10% in any direction for off-axis or high-ceiling installations.

Upgraded Screen Adjustment with New GUI

The PT-VMZ62B introduces an upgraded Screen Adjustment suite with an intuitive new Graphical User Interface (GUI). Designed to simplify setup in various spaces, the GUI streamlines adjustments via remote control without the need for a connected PC, making installation faster, easier, and more flexible than ever. Adjustments include independent 4-corner correction, 6-point adjustment for corner projection, curved screen correction, and the ability to maintain aspect ratio during adjustment.

Key Features

Brightness of 6500 ANSI Lumens
WUXGA (1920 x 1200) Native Resolution
1.09 to 1.77:1 Lens Throw Ratio
3LCD Color with High Dynamic Contrast
Vertical & Horizontal Lens Shift
Advanced Geometric Correction
HDMI, VGA & RJ45 Digital Link Inputs
USB Media Playback
Estimated 20,000 Hours of Laser Life
LAN & RS-232 Control Options

Technical Specifications

Projector type	LCD projectors
Display method	Transparent LCD panel (x 3, R/G/B)
Display Device -> Panel size	16.3 mm (0.64 inch) (16:10 aspect ratio)
Display Device -> Number of pixels	2,304,000 (1920 x 1200) pixels x 3
Light source	Laser diodes
Light output	VMZ82 : 8,000 lm VMZ72 : 7,300 lm VMZ62 : 6,500 lm
Light output (ANSI)	VMZ82 : 8,000 lm (ANSI) VMZ72 : 7,300 lm (ANSI) VMZ62 : 6,500 lm (ANSI)
Time until light output declines to 50 % -> NORMAL	20,000 hours [NORMAL]
Time until light output declines to 50 % -> ECO	24,000 hours [ECO]
Time until light output declines to 50 % -> QUIET	20,000 hours [QUIET]
Resolution	WUXGA (1920 x 1200 pixels)
Contrast Ratio (typ.)	5,000,000:1 (Full On/Full O) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].)
Screen size (diagonal)	0.76–7.62 m (30–300 in), 16:10 aspect ratio
Center-to-corner zone ratio	85 %
Lens	1.6x manual zoom (throw ratio: 1.09–1.77:1), manual focus lens, F=1.58-1.91, f=15.30‒24.60 mm
Digital Zoom Extender	Throw Ratio 1.09–2.21:1 (Corresponding value. When used together with optical zoom.)
Lens shift -> Vertical(from center of screen)	+44 %
Lens shift -> Horizontal(from center of screen)	±20 %
Keystone correction range	Vertical ±25 %, Horizontal ±35 %
Terminals -> HDMI^™ IN	HDMI^TM 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal input), CEC supported
Terminals -> COMPUTER IN（D-SUB 15pin）	D-sub 15-pin (female) (RGB/YP^BP^R/YC^BC^R)
Terminals -> AUDIO IN(M3 Stereo Mini Jack)	M3 stereo mini-jack x 1
Terminals -> AUDIO OUT(M3 Stereo Mini Jack)	M3 stereo mini-jack x 1
Terminals -> SERIAL IN	D-sub 9-pin (female) x 1 for computer control (RS-232C compliant)
Terminals -> DIGITAL LINK IN / LAN	RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT^TM compliant), 100Base-TX (Compatible with PJLink^TM [Class 2],HDCP, Deep Color, 4K/30p signal input)
Terminals -> LAN	RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink^TM[Class 2]
Terminals -> USB TYPE A	USB Connector Type A x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A)
Protocol versions	IPv4, IPv6
Power supply	AC 100–240 V, 50/60 Hz
Maximum power consumption	320 W (3.3 A) (325 VA) (Power consumption is 305 W at 200–240 V)
On-mode power consumption(Operating mode) -> Normal	280 W (100–240 V), 270 W (200–240 V) [NORMAL]
On-mode power consumption(Operating mode) -> Eco	215 W (100–240 V), 205 W (200–240 V) [ECO]
On-mode power consumption(Operating mode) -> Quiet	245 W (100–240 V), 235 W (200–240 V) [QUIET1] 210 W (100–240 V), 200 W (200–240 V) [QUIET2]
Built-in speaker	10 W monaural
Cabinet materials	Molded plastic
Filter	Included
Estimated filter maintenance cycle	Approx. 20,000 hours
Operation noise -> Normal	35 dB [NORMAL]
Operation noise -> Eco	35 dB [ECO]
Operation noise -> Quiet	30 dB [QUIET1] 25 dB [QUIET2]
Dimensions (W x H x D)	399 mm x 115 mm x 348 mm (15 23/32˝ x 4 17/32˝ x 13 11/16˝ ) (not including protruding parts) 399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (with feet at shortest position)
Weight [kg]	Approx. 6.9 kg (15.2 lbs)
Operating environment -> Operating temperature	0–45 °C (32–113 °F)
Operating Environment -> Operating humidity (No condensation)	20–80 % (no condensation)
