Netgear 8-port, 5-speed Unmanaged Switch 10-Gigabit/Multi-Gigabit

Netgear 8-port, 5-speed Unmanaged Switch 10-Gigabit/Multi-Gigabit

Netgear
SKU:
XS508M-100EUS
|
UPC:
606449131116

Pricing available upon request

Limited lifetime warranty
Current Stock:
Description
The XS505M and XS508M come with copper Ethernet 5-speed ports that provide either FastEthernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity, as well as 1 SFP+ Fiber port with 1-Gigabit or 10-Gigabit connectivity.

Plug-and-play

Automatic connectivity to your router or modem of 4 or 7 additional wired connections. No need for an IT expert!

All speeds welcome

Expand your network instantly, and give your devices either 100Mb, 1, 2.5, 5 or 10-Gigabit, automatically

Mounting flexibility

Small and silent desktop or rackmount form factor for quiet operation – Adapts to your needs and configuration in any environment

Industry leading support

ProSAFE LIFETIME Warranty, Next Business Day replacement and 24/7 chat with a NETGEAR expert

Energy efficient

Switches automatically adjust power consumption according to the link status and cable length.

Technical Specifications

XS508M_tech_specs_image_1 XS505M_tech_specs_image_2
  • 100M/1G/2.5G/5G/10G RJ-45 copper ports : 7
  • 10G SFP+ ports : 1 x 10G/1G SFP+ and Copper (combo)
  • Form Factor : Desktop/Rackmount
  • Packet buffer memory : 128KB
  • Bandwidth : 160Gbps
  • MAC Address database size : 2 K
  • Number of priority queues : 8
  • Jumbo frame support : Up to 9K packet size
  • Fan(s) : 1 Low-Noise Active Fan
  • IEEE 802.3az (Energy Efficient Ethernet) : Yes
  • Max power consumption (Watts) : 39W
  • LEDs : Power, Fan, Speed, Link/Activity
  • Acoustic noise level @ 25° C (dBA) : 28dB
  • Operating temperature : 0° to 40° C
  • MTBF (@ 25° C) : 22.5dBA
  • Electromagnetic compliance (A or B) : B
  • Dimensions (W x D x H) : 328 x 169 x 43.2 mm (12.91 x 6.65 x 1.7 in)
  • Weight : 1.49 Kg (3.28lb)
