Logitech MeetUp, RoomMate & Tap IP Video Conference Room Bundle

MEETUP + ROOMMATE + TAP IP

Deploy a complete video conferencing solution for huddle rooms and small spaces with Logitech MeetUp, Tap IP touch controller, RoomMate, and Compute Mount. Set up your room for leading video conferencing platforms, including Zoom Rooms, RingCentral, Microsoft Teams on Android, and others*. Use Logitech Sync to monitor and manage your room solutions and get business insights into how rooms are being used.

ALL-IN-ONE APPLIANCE SOLUTION FOR SMALL MEETING SPACES AND HUDDLE ROOMS

MeetUp is an all-in-one conference camera with an ultra-wide PTZ lens and built-in speakers optimized for small rooms. With Tap IP, employees can join a meeting with just one touch. Adding RoomMate turns any space into an appliance-based video conference room, eliminating the need for an additional compute device. With its compact form factor, RoomMate can be mounted out of sight and out of harm’s way.

Key Features

• Built for small spaces
• Quickstart meetings
• Video conferencing appliance
• Clean and secure mounting
• Management and Insights

Technical Specifications

Meetup

General

• Built-in Components: Ultra-HD camera with motorized pan/tilt, integrated microphone with 3 beamforming elements, full-range speaker, integrated table stand/wall mount
• Enclosure: All-in-one enclosure with patented anti-vibration suspension system
• Remote: RF remote control with three camera presets
• Security: Kensington security slot
• USB 2.0 cable: 5m (16 ft) included; customersupplied USB 3.0 cable required for 4K video
• Dimensions (H x W x D): 104 mm (4.09 in) x 400 mm (15.75 in) x 85 mm (3.27 in)
• Weight: 1.04 kg (2.3 lbs)

Camera

• Lens: Custom Logitech lens with motorized pan/tilt
• Zoom: 5x digital zoom
• Pan: +/- 25°
• Tilt: +/- 15°
• Field of View: Diagonal: 120°, Horizontal: 113°, Vertical: 80.7°
• Total Room Coverage: 163° wide x 110° tall (field of view + pan and tilt)
• 4K Ultra HD: Up to 3840 x 2160 pixels @ 30 fps with customer-supplied USB 3.0 cable
• Full HD: Up to 1920 x 1080 pixels @ 30 fps
• HD: Up to 1280 x 720 pixels @ 30 fps
• RightLight Technologies: Low-light compensation, video noise reduction, low-light saturation optimization

Speaker

• Volume: 95 dB SPL at 1/2 meter peak
• Sensitivity: 86.5+/-3dB SPL at 1/2 meter
• Distortion: 200-300Hz < 3%, 3000 Hz -10KHz < 1%

Microphone

• Beamforming Elements: 3
• Pickup Range: 4 m (13.1 ft)
• Sensitivity: -27 dB
• Frequency Response: 90Hz-16KHz
• RightSound Technologies: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
• Noise Suppression: AI filter
• Date Rate: 32KHz sampling rate
• Add-on Mics: Supports 1 Expansion Mic for MeetUp to expand audio coverage (not included)

RoomMate

• Operating System: Logitech CollabOS 1.4 or higher
• Device Management: Logitech Sync and
• supported device management platforms
• Certified Hardware: Logitech MeetUp, Rally
• Camera, Rally System, Rally Plus System, Tap, Tap IP
• Verified Hardware: Biamp TesiraFORTÉ X 400, QSC, Q-SYS Core 8 Flex, Shure IntelliMix P300. For latest information on compatible products, contact your preferred partner.
• Network Protocol Support: IPv4, IPv6
• Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file Interfaces
• HDMI Out: 2
• HDMI In: 1
• USB: 3x Type A
• Network: 10/100/1G Ethernet
• WiFi: 802.11a/b/g/n/ac
• Operating Voltage/Power: 100-240V, 19V, 4.74A
• Full Disk Encryption: AES-128
• Data Encryption: Symmetric Keys, PKI
• Device Identity: Protected by device attestation
• Device Access: Authenticated using API
• Key Protection: Arm TrustZone, RPMP
• Device Security: Kensington Lock
• Color: White
• Dimensions: (H x W x D): 34.5 mm (1.36 in) x 161 mm (6.34 in) x 211 mm (8.31 in)

Tap IP

• Touch Screen: 257 mm (10.1 in) diagonal screen with 14° display angle
• Resolution: 1280 x 800
• Cabling: Power over Ethernet (PoE) cable (not included), IEEE 802.3af Type 1, Class 3 device
• Cable Management: Internal cable retention and strain relief system
• Ethernet: 10/100mbps
• Wi-Fi: 802.11a/b/g/n/ac
• Device Management: Logitech Sync
• Color: Graphite
• Mounting: 100 mm x 100 mm VESA FDMI
• Dimensions (H x W x D): 58 mm (2.3 in) x 244 mm (9.6 in) x 179 mm (7.0 in)

What's Included

Tap IP

• Tap IP touch controller
• VESA mounting screws (4)
• Microfiber Cloth
• Documentation

RoomMate

• Logitech RoomMate
• Power supply
• AC cable
• VESA bracket
• Remote control
• Documentation

Compute Mount

• Compute Mount with Cable Retention
• Clamp
• Mounting Hardware
• Documentation
