Kramer WP-211T 4K60 4:2:0 HDMI Wall–Plate Auto Switcher/Transmitter Over Long Reach PoE HDBaseT (EU/UK)

WP−211T is a high−performance PoE−powered wall−plate automatic switcher of 4K HDMI video signals, transmitted over long−reach HDBaseT extension link. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.

•  Plug & Play Auto Switcher — Wall or podium mountable switcher, easily accessible for plugging user device to any of its HDMI input connections, it auto–plays switched source signal on connected display according to user–configured preferences.
•  Automatic Input Selection — Plug & play auto switching based on last connected input or manual selection.
•  High Performance Switcher Transmitter — Professional HDBaseT Switcher transmitter for providing long–reach signals over twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market–available HDBaseT–compliant extension product.
•  HDMI Signal Switching — HDMI 2.0 and HDCP 2.2 compliant, it supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D.
•  Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
•  I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
•  Reliable PoE (Power over Ethernet) Powering — Auto–senses the extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
•  Easy Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall–plate installation is fast and cost–effective via a single twisted pair cable, providing both video signal and power (PoE) connections.

Key Features

• 2x1 Plug and Play Wall–mounted Switching
• Up to 4K@60Hz (4:2:0) Resolution
• Up to 70m (230ft) Reach

Technical Specifications

• Inputs: 2 HDMI: On female HDMI connectors
• Outputs: 1 HDBaseT: On an RJ–45 connector
• Video:

  • Max. Data Rate: 8.91Gbps (2.97Gbps per graphic channel)
  • Max. Resolution: 4K@60Hz (4:2:0)
    Standards Compliance: HDCP 2.2 (does not support conversion to HDCP 1.4)
• Extension Line:

  • Up to 40m (130ft): At 4K@60Hz (4:2:0)
  • Up to 70m (230ft): At full HD (1080p @60Hz 36bpp)
  • Up to 70m (230ft): :
  • Note: When using Kramer HDBaseT cables
  • Compliance: HDBaseT 1.0
• User Interface: Controls: Panel buttons, and last connected/priority DIP–switches
• Power:

  • Source: 5V DC
  • PoE: Acceptor
  • Consumption: 780mA
  • Consumption with PoE: 9 watt
• Enclosure:
  • Size: 1 Gang US, EU, or UK wall plate
  • Cooling: Convection ventilation
• Regulatory Compliance:

  • EMC EN 55032
  • IEC 60950–1(ed.2)
  • IEC 60950–1(ed.2)am1
  • IEC 60950–1(ed.2)am2
• Environmental Conditions:

  • Operating Temperature: 0° to +40°C (32° to 104°F)
  • Storage Temperature: –40° to +70°C (–40° to 158°F)
  • Humidity: 10% to 90%, RHL non–condensing
• Product Dimensions: 8.00cm x 3.80cm x 8.00cm (3.15" x 1.50" x 3.15" ) W, D, H
• Product Weight: 0.2kg (0.4lbs) approx.
• Shipping Dimensions: 23.20cm x 13.60cm x 10.00cm (9.13" x 5.35" x 3.94" ) W, D, H
• Shipping Weight: 0.6kg (1.2lbs) approx.

What's Included

• 1 Power adapter
• 1 power cord
• 1 EU white frame
• 1 UK white frame
• 1 EU/UK white faceplate
