Kramer VS-211H2 2x1 4K HDR HDCP 2.2 HDMI Auto Switcher

VS−211H2 is a high−performance auto switcher for 4K@60Hz (4:4:4) HDMI video signals. Offering priority and last−connected auto switching scheme options, it automatically switches input signals to output connection, according to the selected switching scheme, and based on active video signals detection.

•  HDMI Signal Switching — HDR and HDCP 2.2 compliant, it supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
•  Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
•  I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
•  Cost–Effective Maintenance — Status LED indicators for HDMI ports facilitate easy local troubleshooting.
•  Easy Installation — Compact DigiTOOLS® fan–less enclosure fits for convenient under tables or dropped–ceiling mounting, or side–by–side mounting of 3 units in a 1U rack space with the recommended rack adapter.

Key Features

• Up to 18Gbps Data Rate
• Up to 4K@60Hz (4:4:4) resolution
• HDR and HDCP 2.2 compliant

Technical Specifications

• Inputs: 2 HDMI: On female HDMI connectors
• Outputs: 1 HDMI: On a female HDMI connector
• Ports: 2 Contact-Closure Switches: On a 3–pin terminal block connector for remote device operation
• Video:

  • Max. Data Rate: 17.82GBPS (5.94Gbps per graphic channel)
  • Max. Resolution: 4K@60Hz (4:4:4)
  • HDMI Support: Deep Color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
  • Standards Compliance: HDR10, HDCP 2.2 (does not support conversion to HDCP 1.4)
• User Interface: Controls: Status/priority DIP–switches, contact closure remote control
• Regulatory: Certification: EMC EN 55032, IEC 60950–1(ed.2), IEC 60950–1(ed.2)am1, IEC 60950–1(ed.2)am2
• Environmental Conditions:

  • Operating Temperature: 0° to +40°C (32° to 104°F)
  • Storage Temperature: –40° to +70°C (–40° to 158°F)
  • Humidity: 10% to 90%, RHL non–condensing
• Power Consumption: 5V DC, 560mA
• Product Dimensions: 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
• Product Weight: 0.2kg (0.3lbs) approx.
• Shipping Dimensions: 15.70cm x 12.00cm x 8.70cm (6.18" x 4.72" x 3.43" ) W, D, H
• Shipping Weight: 0.6kg (1.4lbs) approx.

What's Included

• Power adapter
