Kramer VP-427X2 4K HDR HDBT Receiver / Scaler Tool with HDBaseT and HDMI Inputs

VP−427X2 is a high−performance auto−switcher/scaler receiver with 2 HDBaseT inputs and a local HDMI input for 4K HDMI™ over extended−reach HDBaseT. It supports automatic and manual glitch−free switching between the 3 inputs, and up− or down−scaling to any resolution up to 4K@60Hz (4:4:4). The output scaling automatically matches the resolution of the HDMI display on the output, or it can be manually set by the user. VP−427X2 enables extending video signals up to 180m over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.

•  Comprehensive Receiver/Scaler — Scales signals of all standard resolutions up to 4K@60Hz (4:4:4) for routing to the HDMI output. Constant output sync prevents signal disruption when switching between inputs and when no video is detected.
•  HDMI Signal Extension — HDCP 1.4 / 2.2. 4K60, CEC, xvYCC color (on input).
•  Audio De–embedding — Analog balanced stereo output for de–embedding the audio to speakers.
•  Data Tunneling — Extend RS–232, IR, and Ethernet over the HDBaseT line.
•  Built–in Automated Control — Includes easy connection to occupancy sensors and contact closure switches.
•  CEC Support — Supports passing of CEC from input to output. Automatically sends CEC commands to shut down the output display after a timeout period when no input signal is found and to power up the display when the input returns.
•  Cost–Effective and Convenient Control Options — Ethernet and RS–232 serial ports, and local control via front panel input selection and OSD menu buttons.
•  ProcAmp Control — Contrast, brightness, color, etc.
•  Convenient Unit Control and Configuration Options — Local control via front panel source switching buttons and OSD menu. Distance control via RS–232 serial commands transmitted by a PC, touch screen system or other serial controllers.
•  Easy, Cost–effective Maintenance — Local firmware upgrade via USB connector.
•  Easy and Elegant Installation — Compact MegaTOOLS™ fan–less enclosure for dropped–ceiling mounting, or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

Key Features

• 2 HDBT and 1 HDMI inputs
• Resolutions up to 4K@60Hz (4:4:4)
• Auto–switching inputs
• Ethernet, IR, RS–232 control and tunneling
• CEC auto display control
• HDCP 2.2 & 1.4 compliant

Technical Specifications

• Inputs:

  • 2 HDBaseT: On an RJ–45 connector
  • 1 HDMI: On a female HDMI connector
• Outputs:

  • 1 HDMI: On a female HDMI connector
  • 1 Balanced Analog Stereo Audio: On a 5–pin terminal block
• Ports:

  • 1 IR: On a 3.5mm mini jack
  • 1 RS–232: On a 3–pin terminal block
  • 1 Ethernet: 100Mbps, on an RJ–45 connector
• Video:

  • Output Resolutions: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz RB, 2560x1600@60Hz RB, 1920x1080@60Hz, 1280x720@60Hz, 2048x1080@50/60Hz, 2560x1440@60Hz RB, 720x480p@60Hz, 720x576p@50Hz, 1280x720p@50/60Hz, 1920x1080p@24/25/30/50/60Hz, 2560x1080p@50/60Hz, 2K@24/25/30/50/60Hz, 4K@24/25/30/50/60Hz
  • Max. Range: 180m at 1080p@60Hz, 100m (328ft) at 4K@60Hz (4:2:0)
  • Latency: Up to 2 frames
  • Content Protection: HDCP 2.2/1.4
  • Switching Time Between Inputs: <2.5 seconds
• User Interface:

  • Control: Input selection buttons, and remote contact–closure switches switches. Kramer API via RS–232 serial commands transmitted by a PC, touch screen system or other serial controller, embedded web pages via LAN for configuration and control
  • Indicators: Power, link, input selection LEDs
• Power:

  • Source: 12V DC
  • Consumption: 2.1A
• Enclosure:

  • Size: MegaTOOLS®
  • Type: Aluminum
  • Cooling: Convection ventilation
• Environmental Conditions:

  • Operating Temperature: 0° to +40°C (32° to 104°F)
  • Storage Temperature: –40° to +70°C (–40° to 158°F)
  • Humidity: 10% to 90%, RHL non–condensing
• Product Dimensions: 18.75cm x 14.50cm x 2.54cm (7.38" x 5.71" x 1.00" ) W, D, H
• Product Weight: 1.1kg (2.3lbs) approx.
• Shipping Dimensions: 35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83" ) W, D, H
• Shipping Weight: 1.7kg (3.8lbs) approx.

What's Included

• Power adapter
• Rubber feet
• Mounting bracket
