VM−400HDCPxl is a 1:4 distribution amplifier for up to 4K@60Hz (4:2:0) HDMI signals, complying with HDCP 1.4 content protection standard, via single−link DVI−I connections. The unit takes one DVI input, equalizes and reclocks the signal, and distributes it to four identical outputs.
- High Performance Distributor — Professional 1:4 DVI distributor for up to 4K@60Hz (4:2:0) video resolution signals. Via single–link DVI–I connections, one HDMI HDCP 1.4 input signal is amplified and distributed to four identical output signals, with signals rebuilt using Kramer Equalization & re–Klocking™ Technology to gain longer distances.
- Secured Operation — Highly–secured operation is ensured by lockable wiring connectivity with protection against unintentional cables connection.
- HDMI Signal Transmission — HDCP 1.4 compliant signal, supporting deep color, x.v.Color™, lip sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0. EDID signals are passed through from the source to the displays.
- EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for DVI source and display systems.
- User–Friendly Operation — Comprehensive signal distribution features and signal mode–forcing options such as RGB forcing, with convenient EDID selection front panel button.
- Cost–Effective Field Maintenance — Mini–USB connection for simple field firmware upgrade using the Kramer K–Upload tool. Status indicators for fast and effective troubleshooting.
- Easy Installation — Compact MegaTOOLS™ fan–less enclosure for over–ceiling mounting, or side–by–side rack mounting.
Key Features
- 1:4 DVI distributor
- Lockable wiring connections
- Up to 4K@60Hz (4:2:0) video resolution
- Up to 10.2Gbps bandwidth
- DVI 1.0, HDCP 1.4 compliance
Technical Specifications
- Inputs: 1 DVI on a DVI–I female connector
- Outputs: 4 DVI on DVI–I female connectors
- Ports: 1 RS–232 on Mini–USB female connector for firmware upgrade
- Video:
- Up to 10.2Gbps bandwidth (3.4Gbps per graphic channel)
- Up to 4K UHD @60Hz (4:2:0) 24bpp resolution
- HDCP 1.4 signal compliance
- Supports deep color, x.v.Color™, lip sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
- Controls: EDID setup button
- Indicator LEDs: OUTPUTS 1 to 4, ACTIVE input and power ON LEDs
- Power Source: 5V DC, 4A
- Power Consumption: 5V DC, 1.1A
- Enclosure: MegaTools size, aluminum type
- Cooling: Convection ventilation
- Operating Temperature: 0° to +40°C (32° to 104°F)
- Storage Temperature: –40° to +70°C (–40° to 158°F)
- Humidity: 10% to 90%, RHL non–condensing
- Product Dimensions: 19.00cm x 11.60cm x 2.70cm (7.48" x 4.57" x 1.06" ) W, D, H
- Product Weight: 0.5kg (1.0lbs) approx.
- Shipping Dimensions: 34.50cm x 16.50cm x 5.20cm (13.58" x 6.50" x 2.05" ) W, D, H
- Shipping Weight: 1.0kg (2.2lbs) approx.
What's Included
- Power supply
- Product Type:
- Amplifiers
