Kramer TAVOR 5-O 5.25" On–Wall 2–Way Powered Speakers (White)
KramerPricing available upon request
The Tavor 5−O is a pair of 5.25−inch powered two−way speakers designed for indoor wall mounting. The active speaker accepts a line−level stereo input and amplifies it using a built−in amplifier and outputs a speaker signal to the passive speaker.
- Active Loudspeaker — Stereo 2x30W RMS, 2x80W continuous program amplifier and volume control.
- Audio Level Controls — Volume, treble and bass.
- Magnetically Shielded.
- Enhanced Bass Reflex.
- Auto Power — Shuts off when system is not in use, indicated by a LED.
- Automatic Input Voltage Selector — 90 to 240V AC, 50 to 60Hz.
- Indoor Wall Mounting.
- Available in Black or White.
- Mounting Configuration — Active speaker: left, passive speaker: right.
- Weight (Single Speaker) — Active speaker 2.7kg (5.95lbs) approx., passive speaker 1.7kg (4.85lbs) approx.
Key Features
- Indoor System
- Woofer — 5.25"
- Tweeter — 0.5"
- Freq — 45Hz to 20kHz
- Volume Control
- 2 Speakers (1 Pair)
Technical Specifications
- Description: 2–way powered speaker
- Built in Power Amplifier: 2x30W RMS, 2x80W continuous program
- Frequency Response: 45Hz to 20kHz @–10dB, 100Hz to 20kHz @±3dB
- Woofer: 5.25” polypropylene cone with rubber edge woofer
- Tweeter: 0.5" Mylar dome tweeter
- Sensitivity: 85dB SPL, 1W@1m
- Max SPL:
- Continuous: 105dB
- Peak: 110dB
- Power Source: 90–240V AC, 50/60Hz
- Crossover Frequency: 8kHz
- Directivity Factor (Q): 5.8 averaged 1kHz to 10kHz
- Directivity Index (DI): 7.6dB averaged 1kHz to 10kHz
- Input Connectors:
- Line level unbalanced stereo audio on a 3.5mm mini jack
- Line level balanced stereo audio on a terminal block connector
- Line level unbalanced stereo audio on left and right RCA connectors
- Output Connectors:
- Speaker (to connect to the external passive speaker)
- 3.5mm mini jack lineout for optional sub–woofer
- 3.5mm mini jack loop output
- Damping Factor: >100 @8Ω/400Hz
- S/N Ratio: >83dB
- THD: <0.2%
- Controls: Volume, bass and treble
- Input Power: On or Auto
- Standby Mode Power Consumption: 0.7W
- Input Signal for System "Wake -Up" from Standby Mode: +8mV to +11mV
- Materials: Aluminum grill, steel brackets, ABS cabinet
- Weight per Single Speaker:
- Active speaker: 2.7kg (5.95lbs) approx
- Passive Speaker: 2.2kg (4.85lbs) approx
- Weight with Mounting Kit:
- Active Speaker: 3.1kg (6.83lbs) approx
- Passive Speaker:2.6kg (5.73lbs) approx
- Shipping Weight (For Pair): 6kg (13.23lbs) approx
- Dimensions with Mounting Brackets: 18.3cm x 17.2cm x 26.5cm (7.2” x 6.8” x 10.4”) W, D, H
- Installation Clearance:
- Front panel to wall (with mounting bracket): 22cm (8.7in)
- Back panel to wall (with mounting bracket): 4.5cm (1.8in)
- Colors: Available in white or black
What's Inclued
- 2 speakers (1 pair)
- 1 pair of U–shaped rotating mounting brackets with 4 mounting bracket screws
- 3m power cord
- 4m loudspeaker cable and a 2m RCA cable
- User manual.
- Product Type:
- Speakers
