Kramer TAVOR 5-O 5.25" On–Wall 2–Way Powered Speakers (White)

Kramer
SKU:
60-000215041

Pricing available upon request

Current Stock:

The Tavor 5−O is a pair of 5.25−inch powered two−way speakers designed for indoor wall mounting. The active speaker accepts a line−level stereo input and amplifies it using a built−in amplifier and outputs a speaker signal to the passive speaker.

  •  Active Loudspeaker — Stereo 2x30W RMS, 2x80W continuous program amplifier and volume control.
  •  Audio Level Controls — Volume, treble and bass.
  •  Magnetically Shielded.
  •  Enhanced Bass Reflex.
  •  Auto Power — Shuts off when system is not in use, indicated by a LED.
  •  Automatic Input Voltage Selector — 90 to 240V AC, 50 to 60Hz.
  •  Indoor Wall Mounting.
  •  Available in Black or White.
  •  Mounting Configuration — Active speaker: left, passive speaker: right.
  •  Weight (Single Speaker) — Active speaker 2.7kg (5.95lbs) approx., passive speaker 1.7kg (4.85lbs) approx.

Key Features

  • Indoor System
  • Woofer — 5.25"
  • Tweeter — 0.5"
  • Freq — 45Hz to 20kHz
  • Volume Control
  • 2 Speakers (1 Pair)

Technical Specifications

  • Description: 2–way powered speaker
  • Built in Power Amplifier: 2x30W RMS, 2x80W continuous program
  • Frequency Response: 45Hz to 20kHz @–10dB, 100Hz to 20kHz @±3dB
  • Woofer: 5.25” polypropylene cone with rubber edge woofer
  • Tweeter: 0.5" Mylar dome tweeter
  • Sensitivity: 85dB SPL, 1W@1m
  • Max SPL:
    • Continuous: 105dB
    • Peak: 110dB
  • Power Source: 90–240V AC, 50/60Hz
  • Crossover Frequency: 8kHz
  • Directivity Factor (Q): 5.8 averaged 1kHz to 10kHz
  • Directivity Index (DI): 7.6dB averaged 1kHz to 10kHz
  • Input Connectors:
    • Line level unbalanced stereo audio on a 3.5mm mini jack
    • Line level balanced stereo audio on a terminal block connector
    • Line level unbalanced stereo audio on left and right RCA connectors
  • Output Connectors:
    • Speaker (to connect to the external passive speaker)
    • 3.5mm mini jack lineout for optional sub–woofer
    • 3.5mm mini jack loop output
  • Damping Factor: >100 @8Ω/400Hz
  • S/N Ratio: >83dB
  • THD: <0.2%
  • Controls: Volume, bass and treble
  • Input Power: On or Auto
  • Standby Mode Power Consumption: 0.7W
  • Input Signal for System "Wake -Up" from Standby Mode: +8mV to +11mV
  • Materials: Aluminum grill, steel brackets, ABS cabinet
  • Weight per Single Speaker:
    • Active speaker: 2.7kg (5.95lbs) approx
    • Passive Speaker: 2.2kg (4.85lbs) approx
  • Weight with Mounting Kit:
    • Active Speaker: 3.1kg (6.83lbs) approx
    • Passive Speaker:2.6kg (5.73lbs) approx
  • Shipping Weight (For Pair): 6kg (13.23lbs) approx
  • Dimensions with Mounting Brackets: 18.3cm x 17.2cm x 26.5cm (7.2” x 6.8” x 10.4”) W, D, H
  • Installation Clearance:
    • Front panel to wall (with mounting bracket): 22cm (8.7in)
    • Back panel to wall (with mounting bracket): 4.5cm (1.8in)
  • Colors: Available in white or black

What's Inclued

  • 2 speakers (1 pair)
  • 1 pair of U–shaped rotating mounting brackets with 4 mounting bracket screws
  • 3m power cord
  • 4m loudspeaker cable and a 2m RCA cable
  • User manual.
Product Type:
Speakers
