Kramer PT-110XL Extended Range Computer Graphi Video Over Twisted Pair Transmit

The PT−110xl is an extended range UXGA line transmitter that receives a UXGA signal and transmits it over a CAT 5/6 cable to the PT−120xl or TP−120 receiver.

Key Features

• Resolution - Up to WUXGA & 1080p.
• HDTV Compatible.
• Power Connect™ System - A single connection to the transmitter or the receiver powers both units when the devices are within 150ft (50m) of each other.
• Extended Transmission Range - Up to 250m (820ft) when used with Kramer’s twisted pair xl receivers (such as PT–120xl, TP–122xl or TP–126xl).
• EDID Capture - Copies and stores the EDID from a display device.
• Increased Noise Immunity - An increased level of protection against noise, spikes and interference in adverse environments.

Technical Specifications

• Connectors:

  • 1 x 15-pin HD VGA/UXGA
  • 1 x RJ-45 Line output
  • 1 x 12 VDC power
• Indicators and Controls:

  • 1 x Capture button
  • 1 x Status LED
  • 1 x ON LED
• Resolution: Up to WUXGA, 1080p
• Transmission Range: Up to 820' (250 m)
• Power Consumption: 12 VDC, 285 mA
• Operating Temperature: 32 to 104°F (0 to 40°C)
• Storage Temperature: -40 to 158°F (-40 to 70°C)
• Humidity: 10 - 90%, RHL non-condensing
• Power Supply: 12 VDC (external)
• Dimensions: 2.4 x 2.6 x 1.0" (6.0 x 6.5 x 2.5 cm)
• Weight: Approx 0.31 lb (0.14 kg)

What's Included

• Power supply
• Rubber feet
