MC3−2Hi is a high−performance two−port HDMI input card which is part of the compatible modular matrices multi−signal cards family. MC3−2Hi can flexibly occupy any of the matrix card slots and its input signals are independently switched by the modular matrix to any of the matrix output ports.
- High Resolution Audio–Visual Experience — Modular matrix input card supports high 4K60 4:4:4 AV signal distribution towards any output port of the modular matrix.
- HDMI™ Signal Distribution — HDCP 2.2 compliant, supporting deep color, x.v.Color™, CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified by the HDMI 2.0 standard.
- Multi–channel Audio Transmission — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
Key Features
- Max. Resolution — 4K@60Hz (4:4:4)
Technical Specifications
- Inputs: 2 HDMI: On female HDMI connectors
- Video:
- Max Data Rate: 18Gbps (6Gbps per graphics channel)
- Max Resolution: 4K@60Hz (4:4:4)
- HDMI Support: HDR 10, 3D, Deep Color, x.v.Color™, ARC, Dolby® TrueHD, Dolby Digital Plus, DTS–HD®, and 7.1 multi–channel audio
- Content Protection: HDCP 2.2/1.4 compliant
- Power Consumption: 5W
- Environmental Conditions:
- Operating Temperature: 0° to +40°C (32° to 104°F)
- Storage Temperature: –40° to +70°C (–40° to 158°F)
- Humidity: 10% to 90%, RHL non–condensing
- Regulatory Compliance (Standards Compliance): Safety: CE
- Product Dimensions: 12.90cm x 24.90cm x 2.00cm (5.08" x 9.80" x 0.79" ) W, D, H
- Product Weight: 0.2kg (0.5lbs) approx.
- Shipping Dimensions: 29.20cm x 16.50cm x 6.00cm (11.50" x 6.50" x 2.36" ) W, D, H
- Shipping Weight: 0.4kg (0.9lbs) approx.
- Product Type:
- Switchers & Matrices
