Kramer BC-2T-300M Stereo Audio/Control Bulk Cable (300m)

Kramer BC-2T-300M Stereo Audio/Control Bulk Cable (300m)

Kramer
SKU:
99-1202300

Pricing available upon request

Current Stock:
Description

Kramer’s BC−2T is a high−quality, dual shielded pair cable designed for routing balanced stereo mic or line level audio signals in commercial or residential AV systems.

  •  Quality Construction — Rugged and flexible jacket with sequential markings every meter.
  •  Easy Stripping — Exceptionally easy to strip because the foil shield is bonded to the inside of the jacket.
  •  Length — Available in reels of 300m (985ft).

Technical Specifications

  • Conductors:
    • Material: Tinned Copper
    • Size: 4x20AWG
    • Diameter: 0.916mm
  • Insulation:
    • Material: PP
    • Diameter: 1.8±0.09mm
    • Average Thickness: 0.442mm
    • Color: As color code
  • Drain Wire:
    • Size: 20AWG
    • Material: Tinned Copper
  • Screening:
    • Material: AL–foil/mylar
    • Overlap: 25% min
  • Jacket:
    • Material: PVC
    • Diameter: 6.2 ± 0.19mm
    • Color: Black
  • Electrical:
    • Temperature rating: 75˚C
    • Insulation resistance: DC–500V 100MΩ/KM MIN. at 20℃
    • Conductor resistance: 20AWG–34.6Ω/KM MAX. at 20℃
    • Impedance: 40~100Ω
  • Standards Compliance:
    • UL: CM
    • RoHS: 2011/65/ EU
Additional Information
Product Type:
Cables & Connectors
