Genelec 4430A 2-Way 5" 100W Powered Smart IP Installation Speaker (Black)

Genelec 4430A 2-Way 5" 100W Powered Smart IP Installation Speaker (Black)

Genelec
SKU:
4430AM

Pricing available upon request

Current Stock:
Description

Styled in a mystic black finish, the Genelec 4430A is a single, bi-amplified Smart IP installation speaker designed to produce precise, intelligible sound quality in even the most challenging acoustic spaces. This compact speaker delivers clarity, reliability, and adaptability and only requires a single CAT cable, making installation and setup easy. The speaker features 100W of Class-D amplification driving a 5” woofer and 3/4” metal-dome tweeter, producing a frequency response of 58 Hz to 20 kHz with a max SPL of 107 dB.

The 4430A's Smart IP technology provides scalable power, audio and loudspeaker configuration, supervision, and calibration via a standard CAT cable, offering integrators unrivalled power, flexibility, cost-effectiveness, and simplicity of installation. The 4430A ships with a Euroblock connector and a bracket with mounting hardware.

At a Glance
  • Highly efficient dedicated Class-D power amplifiers, one for each driver
  • Switched-mode power supply technology, offering high SPL output using standard PoE+ and PoE power supply with an IP switch or power injector
  • Active crossover filter
  • Electronic system protection
  • Audio-over-IP streaming input
  • Balanced analog line input
  • Flexible room acoustic compensation tool set built in

Power to the Speaker

Combining class-leading sound quality with single cable convenience, the 4430A uses PoE to produce uncompromised SPL and acoustic performance, and is fully compatible with both Dante and open streaming standards such as AES67 and ST2110-30. Manufactured in Finland using certified sustainable methods, the 4430A will provide decades of reliable service.

Power to the Installer

As part of the Smart IP family, the 4430A integrates tightly with our Smart IP Manager software—which allows installers to configure an almost unlimited number of rooms, zones, loudspeakers, and audio channels. It includes device discovery, a versatile room EQ tool set, system organization and status monitoring. After which, a public API command set allows the 4430A to be integrated into house automation systems for day to day use.

Created for Professionals
  • Smart IP was created for discerning professionals who demand premium loudspeaker performance that can integrate quickly and seamlessly into any AV application, no matter how complex the project.
  • Powered by PoE and compatible with both Dante and AES67 IP audio streams, Smart IP also offers flexible loudspeaker management to provide system designers, integrators, and installers with a scalable, powerful and cost-effective solution.
Exceptional Audio
  • To deliver pristine audio quality, Smart IP loudspeakers utilize the same two-way active technology that has made Genelec the first choice for demanding studio and broadcast applications for over forty years.
  • Featuring our trademark Minimum Diffraction Enclosure and Directivity Control Waveguide, Smart IP loudspeakers provide clarity, intelligibility, and beautifully uniform coverage, combined with bulletproof 24/7 reliability.
  • There’s much more, though. Smart IP supports uncompressed low-latency audio streaming directly into each loudspeaker, with synchronization to sub-microsecond level for solid acoustic imaging. Each loudspeaker supports up to eight audio channels in a stream with sample rates of 32 to 96 kHz and 16- to 24-bit resolution, all manageable via Dante Controller software.
Total Control
  • Designed to work closely with any Smart IP loudspeaker system, Smart IP Manager software allows installers to configure an almost unlimited number of rooms, zones, loudspeakers, and audio channels, and it includes device discovery, versatile room-equalization tools, system organization, and status monitoring. This enables installers to deploy Smart IP loudspeakers even on highly complex, acoustically challenging projects, with a public API command set to allow external control via third-party hardware, software, or house automation systems. For seamless integration with Control4, QSC Q-SYS and AMX systems, we provide a simple, ready-to-go driver, which can be downloaded and used free of charge.
  • For smaller, less complex installations, the Smart IP Controller app gives the end user day-to-day control of mute, volume control, power on/off and zone control, all via a smartphone or tablet. The Controller app will automatically discover the loudspeakers on the network, and offers a clean and intuitive user interface that both experts and non-technical staff alike will find straightforward and satisfying.
Sustainability
  • Created in conjunction with leading Finnish industrial designer Harri Koskinen, the elegantly minimalist Smart IP loudspeaker enclosures are fashioned from recycled aluminum and are built to the highest environmental standards at our headquarters in Iisalmi, Finland.
  • Designed for low power consumption and offering many years of reliable performance—all backed up by Genelec’s renowned service and support. Smart IP systems are a secure, long-term, and environmentally sound investment.

Key Features

  • 5" Woofer, 3/4" Metal-Dome Tweeter
  • 100W of Optimized Class-D Amplification
  • Switch-Mode Power Supply Technology
  • Power over Ethernet (PoE and PoE+)
  • Active Crossover Filter
  • Electronic System Protection
  • Audio over IP Streaming
  • Euroblock Analog Input
  • Configuration and Control Apps
  • Multiple Mounting Options

Technical Specifications

  • Frequency Response: 58 Hz - 20 kHz (± 1.5 dB)
  • Low cutoff -6dB: 45 Hz
  • High cutoff -6dB: 39 kHz
  • Peak SPL: ≥107 dB
  • Short term max SPL: ≥104 dB
  • Long term max SPL: ≥96 dB
  • Self-generated noise: ≤5 dB
  • Weight: 5.1 kg (11.2 lb)
  • Dimensions
    • Height: 285 mm (11 1/4 in)
    • Width: 189 mm (7 1/2 in)
    • Depth: 178 mm (7 in)
