Ergotron MXV Desk Dual Monitor Arm With Under Mount C-Clamp

Add style to your dual monitor desk without sacrificing functionality. The sleek and lightweight MXV incorporates a modern V-shaped design with proven engineering to create a stable yet flexible platform for your side-by-side screens. This model includes an under mount c-clamp, which features a cleaner look and requires less space for attachment under the edge of the desk’s surface.

With a slim profile, MXV offers 13" (33 cm) of integrated height adjustment, integrated tilt and more—all on a convenient swivel base. The arm’s adjustability helps increase viewing comfort, while its upscale finish leaves a stylish impression.

Key Features

• Under Mount C-Clamp presents a cleaner look when viewing the desk from the back and requires less space to attach underneath the desk edge, so it doesn’t interfere with cable management or structural supports
• Enhance productivity by positioning your work across two screens. Easily turn one or both screens from landscape to portrait mode to view full pages and additional applications without scrolling
• Saves valuable desk space with the cable management system and narrower profile—25% slimmer than the LX arm
• Allows you to easily adjust your display with a light touch thanks to patented Constant Force™ technology
• Creates additional flexibility with a friction pivot that offers a 180-degree tilt
• Supports displays weighing 7 to 20 lbs (3.2 to 9.1 kg)
• Monitor can extend out up to 22.2" (56 cm)
• Sits securely on your workstation with a low-profile desk clamp base that can fit in tight places
• Prevents your arm from making contact with the wall with the base’s rotation-stop, which limits its range to 180 degrees
• Passes Ergotron’s 10,000-cycle motion test, which ensures years of trouble-free height adjustment

Product Specifications

• Product Weight: 5.0 kg
• Shipping Weight: 7.6 kg
• Description: MXV Desk Mount Dual LCD Monitor Arm with Under Mount C-Clamp
• Includes fully assembled arm, under mount c-clamp, monitor attachment hardware
• Can be configured to hold a laptop instead of an LCD display; also order the accessory Notebook Tray (50-193-200)
• Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
• Arm folds back over the base into a compact retracted position; perfect for tucking under systems furniture storage shelves or cabinets in space constrained areas
• One piece formed structural steel
• Set back 0.8" (2 cm) to allow panel dividers to nest behind arm base
• Clamp attaches to surface edge 0.5" to 1.26" (1.2–3.2 cm) thick
• Made for tight installations: C-Clamp protrudes only 0.8" (2 cm)—or 1.4" (3.5 cm) for desks thinner than 1" (2.5 cm)—from bottom of worksurface
• Installation requires 1.2" (3 cm) from edge of desktop to back wall in order to slide clamp on from rear; alternatively, clamp can slide on from the side if open
• Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• § Screens sizes up to 24" can be accommodated though there will be a reduction in adjustment capability
• * Weight Capacity: individual monitor weight = 7 to 20 lbs (3.2 to 9.1 kg); maximum combined weight of displays = 40 lbs (18.1 kg)
• † Tilt Range: 90° backward, 90° forward
• ‡ Pan Range: 180° at base; 360° between extension and arm. Rotation-stop on base can be disengaged at time of installation to increase range to 360°
• Extension Range: 17.8" (45 cm); maximum extension reach = 22.2" (56 cm) from back of base to VESA mounting plate
• Shipping Dimensions: 37.4" x 15.5" x 7.5" (95 x 39.4 x 19 cm)
