Ergotron 200 Series Dual Monitor Arm

The interlocking design of the 200 Series provides telescoping adjustment. Easily extend or retract your monitors through a 23" (58 cm) range of motion.

Key Features

• Position two LCDs at the point of need, then push them back out of the way when not in use
• Touch-screen stability
• Cable management system routes and conceals cables under the arm
• Accommodates various display sizes; slide screens into place to align edges
• Rugged steel construction
• Extends out 23" (58 cm) or folds back to 5.7" (14.5 cm) from wall in storage position
• Rotate screens to view in either landscape or portrait mode

Product Specifications

• Product Weight: 4.4 kg
• Shipping Weight: 5.4 kg
• Description: 200 Series Dual Monitor Wall Mount Arm (black)
• Includes wall mount bracket, 2 extensions, crossbar and 2 sliding LCD mounts, fasteners for wood stud or concrete wall, attachment hardware
• Fasteners for direct attachment to metal studs are not included. When attaching to wall supported with steel studs, the Steel Stud Wall Mounting Kit (60-591-003) is recommended
• Attaches directly to sturdy vertical surfaces. When extra support is needed, order a Wall Plate or Wall Track accessory (Wall Track also requires separately ordered bracket 97-091)
• † Maximum outside width of display is 21.25" (54 cm) when displays are 2" (5 cm) thick. This is typically the horizontal dimension of a 22"-diagonal screen-size monitor. Actual allowable width of displays will vary slightly depending on display thickness
• * Weight Capacity: 13 lbs (5.9 kg) per mount, 26 lbs (11.8 kg) total. Note: Monitors must be equal in weight or ±1 pound (.45 kg)
• Monitor depth greater than 3" (7.5 cm) may diminish capacity
• Install display mounts on the bow at +2.5° or -2.5° angle to optimize viewing conditions
• Monitors are installed with 8° inward off-set angle, creating a 16° viewing parabola for better sight lines
• Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
• Durable, easy-to-clean powder-coated painted steel exterior
• Shipping Dimensions: 5.25"H x 13.75"W x 24.25"D (133 x 349 x 616 mm)
