Epson ELPDC21 Full HD 1080p Document Camera

EPSON
SKU:
V12H758052

Pricing available upon request

Warranty: 1yr Carry-in
Current Stock:
YOUR PARTNER IN ENRICHING THE CLASSROOM EXPERIENCE

Cut through the hassle, and get straight to your presentation. Epsons series of document cameras not only captures details with Full HD resolution, its versatile connectivity also gives you great functionality.

Realistic and Larger Images Larger Imaging Sensor

Achieve sharp, clear images with amazing quality and detail in any light with the large imaging sensor, which captures more light per pixel. The ELPDC21 automatically detects the native aspect ratio of projectors and selects the correct output resolution to match.

12x Optical and 10x Digital Zoom

Zoom in on every intricate detail and let students get up close and personal with the subject at hand. The ELPDC21 delivers a unique perspective on any subject with up to 12x optical zoom and 10x digital zoom. Bring lessons alive, right before their eyes, without having to pass around a microscope or photograph.

Large Capture Area

Open students’ eyes to a whole new world of possibilities. With a large capture area, the ELPDC21 lets you display virtually any object - from a two-page spread in a textbook to 3D objects or content from your smart devices.

Microscope Support

You can even share organisms under a microscopic via the included microscope adapter. Just fit the adapter to any standard microscope eyepiece and bring the smallest particles to the big screen for all to see.

Frame Rate

Watch your presentation come alive with the 30 frames-per-second (fps) video that provides ultra-smooth video performance and minimal delays.

Full HD Image Output

Capture every detail and impress your audiences with brilliant Full HD 1080p resolution.

Versatile Connectivity

Take learning to the next level with engaging multimedia presentations. Output the captured images to any HDMI or VGA display device, as well as to a PC via the USB connections. Enhance any learning experience with attention-grabbing content. You can even capture images and save them to the SD card or connected PC.

Hassle-free Compatibility Interactive Projector Integration

Enjoy instant interactivity with easy-to-use interactive tools. With PC-less annotation, add notes and diagrams to live images with Epson’s interactive projectors. Its compatibility with Epson’s interactive projectors gives you ease-of-control to your presentations.

Epson Easy Interactive Tools (EIT) Software

With PC connectivity, users can use the Epson’s Interactive Tool(EIT) to annotate on the live image. It is even easier with the Epson interactive projector, which allows users to annotate using the interactive feature.

Portable and Compact

Save on space with the sleek and compact design that conveniently folds into a ready-to-carry unit.

Split Screen

Split screen capability enables projection of a live video and still image from a SD card. The versatile remote controller works for both document camera and projector.

Using the split screen, viewers can enjoy both still and moving images.

Record and Share Lessons

Now, it’s easier than ever to capture creative lessons and share them later with other students. Use the document camera and built-in microphone to record classroom demonstrations and projects. Then, play them back for students who missed the class.

Built-in LED Light

The built-in LED light illuminates objects so that you can project objects clearly even if the surrounding area is dimly lit.

Convenient One-touch Control

Enjoy convenient one-touch button to freeze, focus, capture and video record the images.

Key Features
  • Pixels: 2MP (1920 x 1080 pixels)
  • Camera Sensor: 1/2.7 inch CMOS Sensor
  • Resolution: Up to Full HD (1080p)
  • Zoom: 10x Digital Zoom, 12x Optical Zoom
  • Weight: Approx 3.0kg

Technical Specifications

  • Operating Temperature: 5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft) (20% - 80% humidity, No condensation)
  • Main Parts Specification:
    • Sensor:
      • Pick-Up Device; CMOS
      • Size; 1 / 2.7"
      • Effective Pixels; 2M Pixels (1920 x 1080)
      • Frame Rate; Up to 30fps
      • Native Resolution; 1080p (16:9 Aspect Ratio)
    • Video Output:
      • Display Out; SXGA (1280 x 1024) / XGA (1024 x 768) / WXGA (1280 x 800) / HD (1360 x 768) / 1080p (1920 x
      • 1080)
      • HDMI; 480p / 720p / 1080p
      • USB-B; VGA / SVGA / XGA / SXGA / WXGA / 720p / 1080p
  • Optical Systems:
    • Lens:
      • Type; Optical Zoom / Focus
      • F-Number; F = 3.4 - 5
      • Shooting Area; Max 297 x 526 mm at 1080p output resolution
      • Zoom; Up to 10x Digital, Up to 12x Optical
      • Focus; Automatic (need to press "Focus" button), Focus adjust time: less than 2 sec
    • Illumination:
      • Upper; White LED x 2 (variable LED light)
  • Interface Port:
    • Input:
      • D-Sub 15Pin (VGA); 1 (Black)
    • Output:
      • D-Sub 15Pin (VGA); 1 (Blue)
      • HDMI; 1 (in common with CEC control)
      • USB I/O; Type B x 1
      • Internal Microphone; Yes (Monoral)
      • Memory I/O SD Card; 1 (SD / SDHC, No SDXC support)
  • Basic Function:
    • Freeze: Yes
    • Output Source Select: Yes
    • Image Brightness Adjustment: Yes
    • Light Brightness Control: Yes
    • Auto Detect Aspect Ratio: Yes
  • Extended Function:
    • Still Image Capture: Yes (need external SD card)
    • Video Capture: Yes (w/Audio) (need external SD card)
    • Digital Scroll / Pan / Tilt: Yes (available for over 2x digital zoom) (without Zoom window)
    • Image File Play / Slideshow: Yes (need external SD card)
    • Split Screen: Yes
  • Adjustment Function:
    • Image:
      • White Balance; Yes (Auto, Cloudy, Daylight, Fluorescent, Incandescent)
      • Focus Lock; Yes
      • Image Mode; Yes (Normal, Text, Display)
      • Colour / B&W / Negative; Yes (Colour, Black & White, Negative)
      • Image Rotation; Yes (0, 180 degrees)
      • Noise Reduction; Yes
      • Microscope; Yes
      • Focus; Yes (Manual adjustment)
    • Function:
      • HDMI Output; Yes [Auto, SDTV (480p), HDTV (720p), HDTV (1080p)]
      • Output Resolution; Yes [Auto, XGA (1024 x 768), WXGA (1280 x 800), WXGA (1360 x 768), SXGA (1280 x 1024),
      • Full HD (1920 x 1080)]
      • Flicker Reduction; Yes (50Hz, 60Hz)
      • Language; Yes
      • Sleep Mode; Yes
      • HDMI Link; Yes (On / Off)
      • Sleep Mode Timer; Yes
  • Power:
    • Power Supply Voltage: 100 - 240V AC (50/60 Hz)
    • Output Voltage of AC Power Adapter: 12V
  • Dimensions:
    • Open (D x W x H): 502 x 270 x 328 mm
    • Folded (D x W x H): 120 x 375 x 122 mm
    • Weight: Approx. 2.6kg
  • Theft Proof:
    • Kensington Lock: Yes
    • Security Bar: Yes
    • Security Lock Hole: Yes

What's Included

  • USB Cable
  • Computer Cable (VGA Cable)
  • External AC Power Adapter
  • Remote Control: Yes (with 2 AA Batteries)
  • Microscope Adapter
  • Software CD-ROM
  • User Manual CD-ROM
Resolution:
Full HD (1920 x 1080)
Product Type:
Camera
