Epson EB-L520U 5200lms WUXGA 3LCD Laser Projector

Epson EB-L520U 5200lms WUXGA 3LCD Laser Projector

EPSON
SKU:
V11HA30040

Pricing available upon request

Warranty: 3yrs Parts & Labor Carry- In for Projector Main Unit
Current Stock:
Description
Robust, compact WUXGA laser projector with 5,200 Lumens and Optical Zoom

The compact, affordable EB-L520U laser projector delivers powerful performance for education and business applications. Get bright, vivid images with 5,200 lumens of white & colour brightness*2. This robust projector also offers WUXGA resolution. Featuring breakthrough laser technology, it delivers a laser light source of up to 20,000 hours*1 and offers virtually maintenance-free operation with no lamps. Plus, it features an optical zoom of up to 1.6x. It also supports split screen function of up to 4 screens enabling better information sharing and also comes with flexible settings for image enhancement to further sharpen image resolution to your preferences. It is also compatible with the Epson Wireless Presentation System** which enables hassle-free connectivity for better productivity

  • 5200 lumens of color and white brightness*
  • 20,000-hour*1 laser light source with no lamps
  • WUXGA resolution
  • 1.6x Optical Zoom
  • Screen size of up to 500"

Higher Energy Efficiency & Eco-friendly

New laser diode and optical parts quality improvement ensure improved light source output while reducing electricity consumption and other natural resources during use.

Split Screen Function

Supports up to 4 split screens. Connect up to 4 devices simultaneously to share screen and accommodate better information sharing.

Supports 16:6 Wide Screen Setting

Wide and large screen display ensuring optimal visibility, regardless of where you are seated.

Compatible with the Epson Wireless Presentation System**

Improve productivity and deliver interactive meeting styles at an affordable price

Technical Specifications
  • Projection Technology: RGB liquid crystal shutter projection system (3LCD)
  • Connectivity:
    • Network:
      • Wired LAN RJ45 x 1 (100Mbps)
      • Built-in Wireless: N/A
      • Optional Wireless: ELPAP11
    • Analog RGB Input: D-Sub 15Pin: 2
    • Digital Input:
      • HDMI: 2 (HDCP 2.3)
      • HDBaseT: 1 (HDCP 2.3)
    • Audio Input: Stereo Mini Jack: 2
    • Audio Output: Stereo Mini Jack: 1
    • Control I/O: RS-232C: D-Sub 9pin x 1
    • USB Input:
      • USB Type A: 1 (For PC Free, Firmware Update and Copy OSD Settings)
      • USB Type B: 1 (For mouse, K/B, control, firmware)
    • Analog Video Output: D-Sub 15Pin: 1
    • Digital Video Output: N/A
  • Contrast Ratio: Over 2,500,000:1
  • Screen Size (Projected Distance):
    • Zoom : Wide: 50" - 500" [1.44 - 14.76 m]
    • Zoom : Tele: 50” - 500” [2.35 - 23.84 m]
  • Geometric Correction:
    • Vertical/Horizontal Keystone: ±30º / ±30º
    • Projection Orientation: 360º Free
  • Operating Temperature:
    • Single Use:
      • Low Altitude (0 - 2,286m/7,500ft): 0 - 45 °C <32 - 113 °F>
      • High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 - 40 °C <32 - 104 °F>
      • 20% - 80% Humidity, No Condensation
    • Multi-projection Use:
      • Low Altitude (0 - 2,286m/7,500ft): 0 - 40 °C <32 - 104 °F>
      • High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 - 35 °C <32 - 95 °F>
      • 20% - 80% Humidity, No Condensation
  • Operating Altitude: Over 1,500m/4,921ft with High Altitude Mode: 0 - 3,048m (0 -10,000ft)
  • Start-Up Period: 8 sec (Epson Logo); Warm-up Period: 30 sec
  • Quick Start-Up: Less than 5 seconds (Display)
  • Cool Down Period: Instant Off
  • Internal Speaker(s):
    • Sound Output: 10W Monaural
  • Direct Power On/Off: Yes
  • Weight: Approx. 7.7kg
  • Air Filter:
    • Type: Electrostatic Filter
    • Maintenance Cycle*4: 20,000 hours (Normal) / 30,000 hours (Extended)
  • Fan Noise (Normal / Eco): 31dB / 23dB
  • Dimension Excluding Feet (D x W x H): 304 x 440 x 122 mm
  • Brightness:
    • White Light Output (Normal / Extended): 5,200lm / 3,640lm
    • Colour Light Output: 5,200lm
    • Light Output (Center): 5,600lm*
  • Wireless Specification (Using Optional ELPAP11):
    • Supported Speed for Each mode :
      • Infrastructure:
        • IEEE 802.11b (2.4GHz): 11 Mbps*3
        • IEEE 802.11g (2.4GHz): 54 Mbps*3
        • IEEE 802.11n (2.4GHz): 72.2 Mbps*3
        • IEEE 802.11a (5GHz): 54 Mbps*3
        • IEEE 802.11n (5GHz): 150.0 Mbps*3
        • IEEE 802.11ac (5GHz): 325Mbps*3
      • Access Point(Wi-Fi Direct):
        • IEEE 802.11g (2.4GHz): 54 Mbps*3
        • IEEE 802.11n (2.4GHz): 72.2 Mbps*3
        • IEEE 802.11a (5GHz): 54 Mbps*3
        • IEEE 802.11n (5GHz): 150.0 Mbps*3
        • IEEE 802.11ac (5GHz): 325Mbps*3
    • Supported Mode : Infrastructure, Access Point(Wi-Fi Direct)
    • Supported Security Type:
      • Infrastructure:
      • OPEN,
      • WPA2/WPA3-PSK,
      • WPA2/WPA3-EAP
    • Supported EAP type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
    • Access Point(Wi-Fi Direct): WPA2-PSK(AES)
  • Wireless Specification (Screen Mirroring):
    • Supported Speed for Each Mode:
      • Infrastructure:
        • IEEE 802.11b (2.4GHz): 11 Mbps*3
        • IEEE 802.11g (2.4GHz): 54 Mbps*3
        • IEEE 802.11n (2.4GHz): 72.2 Mbps*3
        • IEEE 802.11a (5GHz): 54 Mbps*3
        • IEEE 802.11n (5GHz): 150.0 Mbps*3
        • IEEE 802.11ac (5GHz): 325Mbps*3
      • Access Point(Wi-Fi Direct):
        • IEEE 802.11g (2.4GHz): 54 Mbps*3
        • IEEE 802.11n (2.4GHz): 72.2 Mbps*3
        • IEEE 802.11a (5GHz): 54 Mbps*3
        • IEEE 802.11n (5GHz): 150.0 Mbps*3
        • IEEE 802.11ac (5GHz): 325Mbps*3
    • Supported Mode: Infrastructure, Access Point(Wi-Fi Direct)
    • Supported Security Type:
      • Infrastructure: OPEN, WPA2/WPA3-PSK, WPA2/WPA3-EAP
      • Supported EAP type:
        • PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
        • Access Point (Wi-Fi Direct): WPA2-PSK(AES)
  • Specifications of Main Parts:
    • LCD:
      • Size: 0.67" (C2 Fine)
      • Resolution: WUXGA
      • Aspect Ratio: 16:10
    • Lightsource:
      • Type: Laser Diode
      • Life*1: 20,000 hours (Normal) / 30,000 hours (Extended)
    • Projection Lens:
      • Type: Optical Zoom (Manual) / Focus (Manual)
      • F-Number: 1.50 – 1.70
      • Focal Length: 20 – 31.8 mm
      • Zoom Ratio: 1.0 - 1.60
      • Throw Ratio:1.35 – 2.20 (Wide - Tele)
  • Power Supply Voltage: 100 - 240 V AC ±10%, 50/60 Hz
  • Power Consumption (220 - 240V):
    • Laser Diode ON (Normal / Extended): 293 W / 223W
    • Stand By: (Normal/Eco): 2.0W / 0.3W

What's Included

  • Power Cable
  • Remote Control (with 2x AA Battery)
  • User Guide
Additional Information
ANSI (Lumens):
5200
Resolution:
WUXGA (1920 x 1200)
Product Type:
Projector
