Cisco Meraki MS130-48P Cloud Managed 48GE 740W PoE Switch

Powerful full-size switch with optional PoE+ and mGig

Cisco Meraki MS130 switches provide Layer 2 access switching, ideal for branch and campus deployments. The MS130 series features a variety of options designed to meet the diverse needs of branch and campus deployments.

With 10 different models, capable of providing up to 740W of power over a variety of port densities, including SFP+ capable uplinks, the MS130 line is fully ready to support future wireless infrastructure deployments across a variety of different environments.

Details that matter

• PoE/PoE+ options: 740 W
• Optional: 8x 2.5 GbE mGig ports and 4x 10G SFP+ uplinks
• Configure thousands of ports from a single dashboard
• Layer 2, 802.1X authentication
• MS130 mGig (-X) models are hardware-ready for Adaptive Policy with a future firmware upgrade and Advanced license

Key Features

• Managed via Cisco Meraki Dashboard
• Remote Packet Capture Tools via Meraki Dashboard
• Automatic Firmware upgrades
• SNMP/Syslog Integration
• IPv4/6 ACL support
• 802.1Q VLAN tagging
• DHCP Snooping
• 802.1X Authentication
• 10/100/1000 Mbps RJ45
• 100M/1G/2.5G mGbE RJ45
• 4x 10 Gbe SFP+ models available
• 802.3bt PoE up to 30W per port

Technical Specifications

• 1Gbe RJ45: 48
• mGbe RJ45 (100M/1G/2.5G): -
• 1Gbe SFP: 4
• 10Gbe SFP+: -
• Dedicated Mgmt Interface: 1
• PoE Type: 802.3bt
• PoE Port Budget: 30W
• PoE Switch Budget: 740W
• Power Input: 100-240V~, 12-6A, 50-60Hz
• Power Load (idle/max): 49W/803W
• Operating Temperature:
  • 32°F - 113 °F
  • 0°C - 45°C
• Storage and Transportation Temperature:
  • -4°F - 158 °F
  • -20°C - 70°C
• Humidity: 5% to 95%
• Mounting: Integrated 1U Rack Mount
• Switching Capacity: 104 Gbps
• Power Supply: Fixed Internal
• Fan Operation: Fixed Internal
• Dimensions: 1.73 x 17.32 x 13.4in (4.4 x 44 x 34cm)
• Weight: 12.13 lb (5.5 kg)
