Cisco Catalyst C1300-16FP-2G 16-Port Gigabit PoE+ Compliant Managed Network Switch

Designed for small- to medium-size businesses, the Cisco Catalyst C1300-16FP-2G 16-Port Gigabit PoE+ Compliant Managed Network Switch allows you to operate security cameras, access points, VoIP phones, and other powered devices. It features 16 Gigabit-speed ports, each of which can provide up to 30W of power to compatible devices with a 240W budget. There are also two SFP slots available for 1 Gb/s fiber uplinks.

This rack-mountable managed switch delivers smooth performance with a 36 Gb/s switching capacity and 26.78 Mpps forwarding rate. It also includes advanced Layer 3 features and strong security. Front panel stacking support allows you to manage up to eight switches as though they were one virtual switch. Its fanless design silently dissipates heat without disturbing the environment.

Cisco Business Dashboard

The Cisco Business Dashboard is designed to manage Cisco Business switches, routers, and wireless access points. It simplifies traditional challenges in deploying and managing business networks while automating the deployment, monitoring, and lifecycle management of the network. The 1300 Series switches support an embedded probe as well as direct management, eliminating the need to set up a separate hardware or virtual machine onsite. The device onboarding wizard simplifies the setup and onboarding of new devices to the network.

High Reliability and Resiliency

The Cisco Catalyst 1300 Series Switches support dual images, allowing you to perform software upgrades with minimal network downtime.

Strong Security

Support for advanced network security applications such as IEEE 802.1X and port security tightly limits access to specific segments of your network. Advanced defense mechanisms, including dynamic Address Resolution Protocol (ARP) inspection, IP Source Guard, and Dynamic Host Configuration Protocol (DHCP) snooping, detect and block deliberate network attacks.

IPv6 support

As the IP address scheme evolves to accommodate a growing number of network devices, the Cisco Catalyst 1300 Series Switches can support the transition to the next generation of networking. These switches continue to support previous-generation IPv4, allowing you to evolve to the new IPv6 standard at your own pace and helping ensure that your current network will continue to support your business applications in the future.

Advanced Layer 3 Traffic Management

The Cisco Catalyst 1300 Series Switches enable a more advanced set of traffic management capabilities to help growing businesses organize their networks more effectively and efficiently. For example, the switches provide dynamic Layer 3 routing, allowing you to segment your network into workgroups and communicate across VLANs without degrading application performance.

Front Panel Stacking

This switch supports Front Panel Stacking for up to eight switches, allowing you to configure, manage, and troubleshoot all switches in a stack as a single unit with a single IP address.

Compact Design

The sleek and compact design for the Cisco Catalyst 1300 Series Switches provides additional deployment flexibility, including installation outside the wiring closet for sites such as retail stores, open-plan offices, and classrooms without disturbing the environment.

Key Features

• 16 x Gigabit Ethernet PoE+ Ports
• 2 x Gigabit SFP Ports
• 36 Gb/s Switching Capacity
• 26.78 Mpps Forwarding Rate
• Rack Mountable
• Front Panel Hardware Stacking
• 240W Power Budget
• Passive Cooling
• Layer 3 Features
• IPV6 Support

Technical Specifications

• Layer Services Supported: Layer 2, Layer 3
• Supported Protocols

  • Link Aggregation
  • DHCP Server
  • IGMP Snooping
  • IPv6
  • RADIUS
  • IPv4
  • Head-of-Line (HOL) Blocking
• Queuing: Strict Priority, Weighted Round Robin (WRR)
• Jumbo Frames Support: 9000 Bytes
• Security Features

  • DHCP Snooping
  • DoS Attack Prevention
  • RADIUS Authentication
  • Storm Control
• Forwarding Rate: 26.78 Mpps
• Switching Bandwidth: 36 Gb/s
• Packet Buffer: 1.5 MB
• Flash Memory: 512 MB
• CPU: Dual-Core: Up to 1.4 GHz
• Memory: 1 GB DDR4
• PoE per Port: 30 W
• PoE Power Budget: 240 W
• Power Draw: 281.9 W (Max)
• Input Power: 100 to 240 VAC, 60 / 50 Hz
• Power Supply Type: Internal
• Certifications: CE, CSA, FCC, UL
• Operating Conditions: 23 to 122°F / -5 to 50°C at 10 to 90% Humidity
• Storage Conditions: -13 to 158°F / -25 to 70°C at 10 to 90% Humidity
• Cooling System: Passive
• Mean Time Between Failures (MTBF): 0.31 Million Hours
• Material of Construction: Metal
• Indicator Lights: Yes
• Rack Mountable: Yes
• Dimensions: 12.7 x 10.6 x 1.7" / 323.3 x 268 x 44 mm
• Weight: 5.49 lb / 2.49 kg
