B-Tech BT8332-CL1x1-110-F-150/B Universal Ceiling Mounted Menu Board Mounting System, 1.5m

The BT8332 is a modular ceiling mounting system for menu board installations of any size. The BT8332 can mount screens in landscape or portrait orientations with the option for tilt adjustment up to +20° for enhanced overhead visibility, perfect for fast food restaurants. As part of the System X range, the BT8332 can be used in thousands of different configurations and must be ordered according to your requirements using B-Tech's online configuration tool.

Key Features

• Universal design suitable for all sized screens up to 50kg (110lbs) (per screen)
• High-end aesthetic quality
• Suitable for landscape or portrait mounting
• Choice of fixed or tilting interface arms available to suit a range of installs
• Suitable for landscape, portrait and back-to-back mounting
• Interface arms available for portrait mounting XXL screens with vertical fixings
  up to 800mm (31.5") or 1200mm (47.2")
• All arms feature levelling screws to adjust the screen height
• Tilting arms feature up to +20° tilt adjustment for enhanced overhead visibility
• Multiple rail lengths available (rails can be also be joined)
• TUV certified

Technical Specification

• Recommended screen size: 32" (81cm) - 75" (190cm)
• Max load: 50kg (110lbs) (per screen)
• Tilt range (where applicable): +20°
• Tilt range (tilt arms only): +20°
• VESA® & non-VESA fixings: up to 900mm*
• Pole Length: 0.5m (19.7") up to 3m (118.1") (can be cut or joined)
• Colour options (poles & ceiling mount): Black
• Colour options (rails): Black

*Refers to maximum vertical fixing dimension for a typical configuration. Correctly sized interface arms and adaptors will be supplied as necessary to suit the mounting pattern you require..
