AVer VB370A Dual Lens PTZ 4K Video Bar

4K Dual Lens Video Bar

The AVer VB370A 4K dual-lens video conferencing bar delivers superior video and audio quality, ensuring every participant feels present. Smart AI-driven Voice Tracking* guarantees clear communication, while the ready-to-go setup makes connecting simple. Designed for mid-to-large spaces, the VB370A supports dual-screen displays and can easily scale to accommodate growing teams. Being certified by Zoom and powered by Android™ allows the VB370A to deliver truly engaging and productive virtual meetings.

Synergy in Action. Android™-Driven.

The VB370A is powered by Android™, offering a high-quality and consistent Zoom Rooms experience. Designed for enterprise-level performance, it ensures reliability and compliance for every meeting. The intuitive interface simplifies setup and allows users to join meetings with a single touch, making it easy to get started quickly.

Zoom-Optimized for Effortless Collaboration.

Certified by Zoom, the VB370A offers a seamless conferencing experience. Its compatibility with Zoom Rooms features, including content sharing, results in smooth presentations and teamwork. Enjoy crisp video and audio quality that boosts meeting efficiency and professionalism. This Zoom-tailored solution provides a hassle-free experience from start to finish.

AI Voice Tracking: Your Voice. Our Focus.

Experience the power of AI with the VB370A's intelligent Voice Tracking technology. This technology automatically shifts the camera to focus on whoever is speaking, creating a distraction-free experience. By keeping the speaker in clear view, it makes virtual meetings feel more personal and supports a team-focused atmosphere.

Stunning Video. Captivating Sound.

The VB370A's 4K cameras provide sharp visuals, guaranteeing that every participant is seen. With advanced audio technology, it captures crystal-clear audio from all directions, eliminating any garbled double talk. This superior combination of video and audio quality creates an immersive, natural meeting experience, enabling users to communicate and engage without barriers, regardless of the environment.

Double Screens. Double Your Impacts.

Expand your collaboration with dual-screen support and stunning 4K visuals. The VB370A's instant setup and sleek design make it a streamlined addition to any modern workspace. By viewing the speaker and content on two screens simultaneously, participants can immerse themselves in high-resolution visuals and enhance productivity.

Versatile Meetings in Your Ways.

The VB370A easily expands your audio capabilities by connecting additional speakerphone and microphone option, ensuring optimal sound quality in any environment. When combined with a touch panel, the VB370A transforms into a comprehensive conferencing solution without the hassle of complicated setups.

Harware Spec

Front

1. Microphones
2. LED Indicator
3. Fixed Camera
4. PTZ Camera
5. IR Sensor

Back

1. Cable Clips
2. Kensington Lock

Side

1. DC 12V
2. LAN Port
3. USB Type-C Port for PC
4. Reset Button
5. HDMI In Port
6. USB 3.0 Type-A Port
7. Phone In Port
8. Expansion Device Port
9. HDMI Out Port 1
10. HDMI Out Port 2
11. Bluetooth®/Wi-Fi Dongle Port

Technical Specificaitons

• PTZ Camera
  • Image Sensor: 1/2.8” 4K Sony Exmor CMOS
  • Effective Picture Elements: 8 Megapixels
  • Output Resolutions: Up to 4K/30
  • Minimum Illumination: 0.46 lux (IRE50, F1.6, 30fps)
  • S/N Ratio: ≥ 50 dB
  • Gain: Auto
  • TV Line: 1500 (Center)
  • Shutter Speed: Auto
  • Exposure Control: Auto
  • White Balance: Auto, Manual
  • Hybrid Optical Zoom: 4.5X
  • Digital Zoom: 4X
  • Total Zoom: 18X
  • Viewing Angles:
  • DFOV: 92°
  • HFOV: 81°
  • VFOV: 50°
  • Viewing Area: Pan: 141°, Tilt: 78°
  • Preset Positions: 128*
  • Camera Control - Interfaces: IP, USB*, Remote Control, AVer CP10 G2, Zoom Rooms Controller App
  • Camera Control - Protocols:
  • VISCA (IP)*
  • CGI (IP)
  • USB*
  • Image Processing: WDR, 3D/2D Digital Noise Reduction
  • Power Frequencies: 50 Hz, 60 Hz
• Fixed Camera
  • Image Sensor: 1/2.5” 4K Sony Exmor CMOS
  • Effective Picture Elements: 8 Megapixels
  • Output Resolutions: Up to 4K/30
  • Viewing Angles:
  • DFOV: 120°
  • HFOV: 110°
  • VFOV: 75°
  • Viewing Area: Pan: 170°, Tilt: 103°
• Speaker
  • Volume: 96 dB SPL at 0.5 Meter Peak
  • Sensitivity: 81 ±2dB SPL at T/S Parameter
  • Frequency Response: 110 Hz to 20 KHz
  • Sample Rates: 48 KHz
• Microphones
  • Beamforming Elements: 14
  • Pickup Range: 10 Meters
  • Sensitivity: -35 ±1dB FS
  • Frequency Response: 100 Hz to 12 KHz
  • Acoustic Echo Cancellation (AEC): Yes
  • Automatic Gain Control (AGC): Yes
  • Noise Suppression: Yes
  • Sample Rates: 24 KHz
  • Add-on Microphones: Yes
  • Expansion Microphone: Yes (One Microphone Only)
  • Expansion Speakerphone: Yes (One Speakerphone Only)
• Interfaces
  • HDMI Out: 2
  • HDMI In: 1
  • USB: USB Type-A x 3, USB 3.0 Type-C* (DisplayPort Alternate Mode) x 1
  • Network: RJ-45 x 1
  • Line In: 1
  • Audio In/Out: RJ-45 x 1
  • Wi-Fi*: 802.11 a/b/g/n/ac
  • Bluetooth^®*: Bluetooth^® Low Energy
• General
  • Operating System: Android^™ 13
  • Power Requirement: AC 100 - 240V to DC 12V/7.5A
  • Power Consumption: 90W
  • Dimensions (W x H x D): 790 x 129 x 138 mm
  • Net Weight: 3.7 ±0.1 kg
  • Application: Indoor
  • Security: Kensington Slot
  • Remote Control: Infrared
  • Operating Conditions: Temperature: 0 °C to +40 °C, Humidity: 20% to 80%
  • Storage Conditions: Temperature: -20 °C to +60 °C, Humidity: 20% to 80%
• USB
  • Connector: USB 3.1
  • Video Format: YUY2, MJPEG
  • Audio Format: PCM
  • Maximum Video Resolution: 4K 30fps
  • USB Video Class (UVC): UVC 1.1
  • USB Audio Class (UAC): UAC 2.0
• Web UI
  • Live Video Preview: Yes
  • Camera PTZ Control: Pan, Tilt, Zoom, Focus, Preset Control
  • Camera/Image Adjustment: Exposure, White Balance, Picture
  • Network Configuration: DHCP, IP Address, Gateway, Subnet Mask, DNS
• AVer AI Technologies
  • Onboard AI: Yes
  • Video AI*: Smart Composition, Auto Framing
  • Audio AI*: Voice Tracking, Audio Fence, Beamforming Technology
• Certifications
  • Zoom
    • Built-in Zoom Rooms
    • Functions: Auto-Framing, Multi-Focus Framing, Speaker Focus, Multi-Stream (Smart Gallery)
• Compatability
  • Software & Apps (for BYOD Mode)*: Zoom, Microsoft^® Teams, Skype, Google Meet™, Intel^® Unite^™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting^®, TrueConf, Adobe^® Connect, Cisco WebEx^®, Fuze, GoToMeeting^™, Microsoft^® Lync^™, Vidyo, vMix, WebRTC, Wirecast, XSplit, V Cube

What's Included

• VB370A
• Power Adapter
• Power Cable
• Remote Control
• HDMI Cable
• Tripod Screw (x2)
• Wall-Mount Bracket
• Drilling Paper
