Audio-Technica AE-3300 Cardioid Condenser Handheld Microphone

Audio-Technica AE-3300 Cardioid Condenser Handheld Microphone

Audio-Technica
SKU:
AE3300

Pricing available upon request

Current Stock:
Description

The Audio-Technica AE3300 is a professional condenser handheld microphone designed to provide the level of audio quality necessary for the most demanding applications. The AE3300 is primarily intended for capturing vocals although it's wide, linear frequency response and low noise floor enable the microphone to accurately capture instruments as well. The rugged capsule houses the same element found in the famed AT4033 microphone.

The element features a cardioid polar pattern which rejects off-axis signal and noise caused by room ambiance, adjacent instruments and monitor speakers that cause feed back. The durable grille and anti-shock engineering ensures maximum protection against noise and damage caused by handling and shock. The grille also provides multiple stages of protection against noise caused by plosives. The rugged design and exceptional audio quality allows the AE3300 to perform well in professional sound reinforcement, ENG/EFP applications and professional recording.

Cardioid Polar Pattern
The well-tempered cardioid polar pattern provides exceptional rejection of off-axis audio signal and noise.

Wide Frequency Response
The wide 30Hz to 18kHz linear frequency response provides an accurate pick up response for vocals and instruments.

High Pass Filter
The high pass filter switch eliminates hum and noise below 80Hz.

Pad Switch
The Pad switch provides an additional 10dB of headroom and reduces noise caused by distortion and signal overload.

Multi-Stage Grille
The rugged grille provides multiple layers of protection against damage and noise caused by plosives.

Anti-Shock Engineering
An integral anti-shock system protects the element against handling noise.

Key Features
  • Exceptional performance for exceptional performers
  • Same element as the classic AT4033 studio microphone
  • Well-tempered polar pattern with outstanding rejection qualities
  • Superior anti-shock engineering ensures low handling noise and quiet performance
  • High-quality double-sided PCB uses surface-mount components. Extensive grounding plane and attention to best-practice grounding methods minimize electrical noise
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Multi-stage grille design offers excellent protection against plosives and sibilance without compromising high-frequency clarity
  • Robust all-metal design for enduring dependability on the road
  • Quiet-Flex™ stand clamp provides silent, flexible microphone positioning
  • Integral 80 Hz HPF switch and 10 dB pad

Technical Specifications

  • Element: Fixed-charge back plate, permanently polarized condenser
  • Polar Pattern: Cardioid
  • Frequency Response: 30-18,000 Hz
  • Low Frequency Roll Off: 80 Hz, 12 dB/octave
  • Open Circuit Sensitivity: -42 dB (7.9 mV) re 1V at 1 Pa
  • Maximum Input Sound Level:
    • 147 dB SPL, 1 kHz at 1% T.H.D.;
    • 157 dB SPL, with 10 dB pad (nominal)
  • Noise: 19 dB SPL
  • Dynamic Range: 128 dB, 1 kHz at Max SPL
  • Signal-to-Noise Ratio: 75 dB, 1 kHz at 1 Pa
  • Phantom Power Requirements: 11-52V DC, 3 mA typical
  • Switches:
    • High-pass filter
    • 10 dB pad (nominal)
  • Weight: 10.6 oz (300 g)
  • Dimensions:
    • 7.05" (179.0 mm) long
    • 1.97" (50.0 mm) head diameter
    • 1.30" to 0.87" (33.0 mm to 22.0 mm) tapered body diameter
  • Output Connector: Integral 3-pin XLRM-type
  • Audio-Technica Case Style: T4

What's Included

  • Audio-Technica AE-3300 Cardioid Condenser Handheld Microphone
  • AT8470 5/8"-27 Thread Quiet-Flex stand clamp
  • 5/8"-27 Thread to 3/8"-16 Threaded Adapter
  • Soft Protection Pouch
Additional Information
Product Type:
Microphone
