Warranty: 2 Years
The ATEN VC010 is a VGA EDID Emulator, which is designed to emulate and store the EDID of a video display, providing constant and reliable EDID data for the a VGA source device to efficiently optimize video resolution.
The ATEN VGA EDID Emulator is a convenient tool that ensures smooth viewing experience for any video installation. The EDID Emulator provides three flexible methods for selecting and switching between EDID Modes: Default Mode, Programming Mode, and Learning Mode. It comes with an easy-to-use EDID Wizard that allows users to quickly view, store and manage EDID settings.
Key Features
- Superior video quality – HDTV resolutions of 480i, 480p, 720i, 720p, 1080i, 1080p (1920 x 1080); VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
- EDID Wizard – allows a user an easy way to manage EDID settings
- EDID mode selection – Default, Learning , Programming
- Automatically manages EDID communication between connected devices
- Signaling rates up to 2.25 Gbits in support of 1080p display
- LED indication of video source devices
- Supports wide screen
- Supports hot-plugging
- Non-Powered *
* If the video source is not receiving enough power an external power cord should be connected.
Technical Specifications
- Video Input
- Interfaces: 1 x HDB-15 Female (Blue)
- Impedance: 75 Ω
- Video Output
- Interfaces: 1 x HDB-15 Female (Blue)
- Impedance: 75 Ω
- Video
- Data Rate: 2.25 Gbits
- Max. Video Resolution: WUXGA (1920 x 1200)
- EDID Settings
- EDID Mode: Default / Learn / Customized (EDID Wizard support)
- Connectors
- Power: 1 x DC Jack
- Power Consumption
- DC5V:0.11W:1BTU/h
- Note:
- The measurement in Watts indicates the typical power consumption of the device with no external loading.
- The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
- Environmental
- Operating Temperature: 0-50°C
- Storage Temperature: -20 - 60°C
- Humidity: 0 - 80% RH, Non-Condensing
- Physical Properties
- Housing: Metal
- Weight: 0.15 kg ( 0.33 lb )
- Dimensions (L x W x H): 7.90 x 7.76 x 2.45 cm (3.11 x 3.06 x 0.96 in.)
What's Included
- 1x VC010 VGA EDID Emulator with Programmer
- 1x RS-232 Configuration Cable
- 1x USB to DC Power Cord
- 1x User Instructions
- Product Type:
- Video Converters
