ATEN VGA EDID Emulator

The 2A-130G VGA EDID Emulator is designed for ATEN KVM extender or video extender installations that do not utilize a local monitor at the site where the computer/video source is located. The 2A-130G emulates and stores a default ATEN EDID (Extended Display Identification Information) setting in a non-volatile memory. This means the computer/video source can still "see" the display, even though it is not directly connected.

The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.

Key Features

• Subsitutes as a monitor at the site where the computer/video source is located
• EDID built-in - Stores ATEN standard EDID information in device
• ATEN standard EDID supports all popular resolutions
• Superior video quality - up to 1920 x 1200@60Hz, 1366 x 768@60Hz
• USB Powered - No need for an external power adapter
• No software required - Eliminates incompatibility and installation issues; no need to confi gure
• Compatible Extenders: CE774, CE775, CE700A, CE750, CE770, CE800B, CE350, CE370, CE250A, CE252, VE150A, VE170, VE200, VE300, VE500
• Compatible Splitters (Connect to Port 1): VS132A/134A/138A, VS92A/94A/98A, VS82/84/88, VS0116, VS132, VS102, VS1204T, VS1208T, VS1504, VS1508
• Supported Resolutions

Technical Specifications

• Connectors

  • Video: 1 x HDB-15 Male (Blue)
  • Power: 1 x USB Type A Male
• LEDs

  • Power: 1 (Green)
• Video
  • 1920 x 1200@60Hz
  • 1366 x 768@60Hz
• Cable Length: 0.35 m
• Power Consumption:
  • DC5V:0.1W:1BTU/h
  • Note:

    • The measurement in Watts indicates the typical power consumption of the device with no external loading.
    • The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
• Environmental

  • Operating Temperature: 0-50°C
  • Storage Temperature: -20-60°C
  • Humidity: 0-80% RH, Non-condensing
• Physical Properties

  • Housing: Plastic

What's Included

• 1x 2A-130G VGA EDID Emulator
