ATEN USB DP Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)

ATEN USB DP Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)

ATEN
SKU:
CE924-AT-E

Pricing available upon request

Warranty: 2 Years
Current Stock:
Description


The ATEN CE924 USB DisplayPort Dual View HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K video, stereo audio, USB, and RS-232 signals. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as it provides long-reach capability that extends Full HD 1080P signals up to 150 meters. In addition, CE924 supports single 4K display or dual 1080p display for DisplayPort video output resolution up to 100m by using a single Cat6 / 2L-2910 Cat 6 cable.

With an easy cable installation supporting various signals, the CE924 is ideal for applications where convenient remote access is required – such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.

Key Features

  • Allows dual view DisplayPort access to a computer and KVM control from a remote console
  • Supports HDBaseT 2.0 technology
    • Extends video, audio, USB, and RS-232 signals via a single Cat6 / 6a / 2L-2910 Cat 6 cable
    • Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
    • Status detection and LED indication for HDBaseT™ signal transmission on the remote unit
  • EDID Buffer for smooth power-up and the highest quality display
  • Single category cable to transmit AV and control signal
    • HDBaseT Standard mode up to 4K @ 100 m (via Cat 6 / 6a / 2L-2910); (single view only; dual-view resolution up to 1080p)
    • HDBaseT Long-Reach mode up to 1080P @ 150 m (single view only; dual-view resolution up to 720p)
  • Supports 4 ports USB 2.0 full speed hub on the receiver – allowing to connect up to 4 various USB 2.0 peripheral
  • HDCP Compatible
  • Supports individual 2-channel stereo audio for high-quality audio applications
  • Supports PC wakeup function via single pushbutton through RS-232 channel
  • Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)

Technical Specifications

CE924L

  • Connectors
    • KVM Ports:
      • 2 xDisplayPort Female (Black)
      • 1 x USB Type B Female (White)
      • 1 x Mini Stereo Jack Female (Green)
      • 1 x Mini Stereo Jack Female (Pink)
    • Console Ports: N/A
    • RS-232: 1 x DB-9 Female (Black)
    • Power: 1 x DC Jack with locking
    • Unit To Unit: 1 x RJ-45 Female (Black)
  • LEDs
    • Power: 1 (Green)
    • Link: 1 (Orange)
    • Video Output: N/A
  • Switches
    • Long Reach Mode Switch: 1 x Slide Switch
    • Firmware Upgrade: 1 x Slide Switch
  • Pushbuttons
    • Wakeup button: N/A
  • Video
    • Single view: Up to 4K@90m (Cat 5e) / 100m (Cat 6/6a/ATEN 2L-2910 Cat6)
    • 1080P@100m (Cat 5e/6/6a/ATEN 2L-2910 Cat6)
    • Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-2910 Cat6)
    • 4K supported: 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
  • Power Consumption
    • DC12V:7.03W:33BTU/h
    • Note:
      • The measurement in Watts indicates the typical power consumption of the device with no external loading.
      • The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
  • Environmental
    • Operating Temperature: 0–40°C
    • Storage Temperature: -20–60°C
    • Humidity: 0–80% RH, Non-condensing
  • Physical Properties
    • Housing: Metal
    • Weight: 0.82 kg ( 1.81 lb )
    • Dimensions (L x W x H): 17.42 x 15.41 x 2.88 cm (6.86 x 6.07 x 1.13 in.)
  • Note: DisplayPort support up to 4Kx2K @ 30Hz, not supports 4Kx2K @ 60Hz, 4:2:0; also not support MST mode.

CE924R

  • Connectors
    • KVM Ports: N/A
    • Console Ports:
      • 2 x DisplayPort Female (Black)
      • 4 x USB Type A Female (White)
      • 1 x Mini Stereo Jack Female (Green)
      • 1 x Mini Stereo Jack Female (Pink)
    • RS-232: 1 x DB-9 Male (Black)
    • Power: 1 x DC Jack with locking
    • Unit To Unit: 1 x RJ-45 Female (Black)
  • LEDs
    • Power: 1 (Green)
    • Link: 1 (Orange)
    • Video Output: 2 (Orange)
  • Switches
    • Long Reach Mode Switch: 1 x Slide Switch
    • Firmware Upgrade: 1 x Slide Switch
  • Pushbuttons
    • Wakeup button: 1 x Push button
  • Video
    • Single view: Up to 4K@90m (Cat 5e) / 100m (Cat 6/6a/ATEN 2L-2910 Cat6)
    • 1080P@100m (Cat 5e/6/6a/ATEN 2L-2910 Cat6)
    • Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-2910 Cat6)
    • 4K supported: 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
  • Power Consumption
    • DC12V:9.92W:69BTU/h
    • Note:
      • The measurement in Watts indicates the typical power consumption of the device with no external loading.
      • The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
  • Environmental
    • Operating Temperature: 0–40°C
    • Storage Temperature: -20–60°C
    • Humidity: 0–80% RH, Non-condensing
  • Physical Properties
    • Housing: Metal
    • Weight: 0.85 kg ( 1.87 lb )
    • Dimensions (L x W x H): 17.42 x 15.57 x 2.88 cm (6.86 x 6.13 x 1.13 in.)
  • Note: DisplayPort support up to 4Kx2K @ 30Hz, not supports 4Kx2K @ 60Hz, 4:2:0; also not support MST mode.

What's Included

  • 1x CE924L USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Local Unit)
  • 1x CE924R USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Remote Unit)
  • 2x DisplayPort cables
  • 1x pink audio jack cable set
  • 1x green audio jack cable set
  • 1x USB Type-A to Type-B cable
  • 2x power adapters
  • 2x mounting kits
  • 1x user instructions
Additional Information
Product Type:
KVM Extender
