ATEN USB-C Multiport Mini Dock with Power Pass-Through

ATEN USB-C Multiport Mini Dock with Power Pass-Through

ATEN
SKU:
UH3239-AT

Pricing available upon request

Warranty: 2 Years
Current Stock:
Description

The UH3239 USB-C Multiport Mini Dock with Power Pass-Through is a portable, versatile and flexible 6-in-1 adapter for USB-C PCs or laptops. The durable aluminum enclosure ships with dual USB 3.2 Type-A ports, a USB-C PD port, an HDMI port along with an SD card and a MicroSD card slots. It covers users' peripheral connectivity demands while allowing power delivery to the connected USB-C device. It supports resolutions up to 4K HDMI (3840 x 2160 @ 30Hz) to ensure that every detail of the video is displayed in the crisp and sharp UHD resolution on the 4K graphics-supported laptop. Besides, its 2 USB 3.2 Gen 1 Type-A ports guarantee effective communication with peripherals at a decent 5 Gbps transmission speed. Thanks to the USB-C PD port, the UH3239 can provide power or charge the external devices, and hence, there will be no more tangled data cables on the desk.

The UH3239 is a plug-and-play device compatible with all major operating systems (Windows®, macOS X and iPadOS). It is a compact, yet competent, data and power transmission solution for on-the-go professionals when it comes to building a mobile workstation ecosystem.

Key Features

  • 6-in-1 multi-function dock that includes 1x HDMI, 1x SD / Micro SD card reader, 1x USB-C PD port and 2x USB 3.2 Gen 1 Type-A ports
  • Supports USB PD 2.0 for laptop charging up to 60W via USB-C PD power adapter – power profiles include 5V, 12V, 15V, 20V
  • Supports resolutions up to 4K (3840 x 2160 @ 30Hz) for superior video distribution
  • Plug and Play – no drivers needed
  • Works with all major operating systems: Windows®, macOS X and iPadOS
  • Compatible with Thunderbolt™ 3 (USB-C)
  • Apple M1 chip compatible

Technical Specifications

  • Computer Connections: 1
  • Cable Length: 55cm
  • Connectors
    • Computer: USB 3.2 Gen1 Type-C Male Cable
    • Device:
      • 2 x USB 3.2 Gen 1 Type-A female (Max. output 5V, 4.5W for each)*
      • 1 x USB 3.2 Gen 1 Type-C female (Max. output 5V, 12W)*
      • * 2 x USB-A and 1 x USB-C ports share total 5V, 12W when UH3239 powered by PC via USB-C. (@5V,3A bus-powered)
    • Video Output: 1 x HDMI Female (Black)
    • Power:
      • 1 x USB Type-C Female (supports USB 3.2 Gen1 Type-C Port data transfer)
      • Support Power Delivery 2.0 for laptop charging up to 60W, power profiles include 5V, 12V, 15V, 20V (additional USB-C power adapter needed)
  • Performance
    • Flash Memory:
      • Supports SD V1.0/ v1.1/ v2.0/ V3.01 and V5.0
      • SD (Capacity up to 2GB)
      • SDHC (Capacity up to 32GB)
      • SDXC (Capacity up to 2TB)
  • Video Resolution: 3840 x 2160@30Hz
  • Power Consumption:
    • DC5V:15WBTU/h
    • Note:
      • The measurement in Watts indicates the typical power consumption of the device with no external loading.
      • The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
  • System Requirements:
    • Windows 10 or later, USB-C enabled computer with DP Alt Mode*
    • * With Intel 7th-Generation Core Processor (Kaby-Lake) and above. More info about CPU generation, please find: https://www.intel.com/content/www/us/en/processors/processor-numbers.html
    • Mac OS X 10.12 or later, USB-C enabled computer
    • iPadOS 13.1 or later, iPad Pro (USB-C)
  • Environmental
    • Operating Temperature: 0-40˚C
    • Storage Temperature: -20-60˚C
    • Humidity: 0–80% RH, Non-condensing
  • Physical Properties
    • Housing: Aluminum
    • Weight: 0.07 kg ( 0.17 lb )
    • Dimensions (L x W x H): 13.30 x 3.60 x 1.10 cm (5.24 x 1.42 x 0.43 in.)

What's Included

  • 1 x UH3239 USB-C Multiport Mini Dock with Power Pass-Through
  • 1 x user instructions
Additional Information
Product Type:
USB Hubs
