Warranty: 2 Years
The UCE260 USB 2.0 Extender can be used to extend a USB signal using a Cat5/5e/6 cable to a device up to 196' away. The extender is hot-pluggable and does not require a software driver to be installed. An AC adapter is included for stabilizing the power supply.
Key Features
- Extends a USB signal up to 196'
- Power adapter included
- Hot pluggable
Technical Specifications
- Connector
- Local Unit:
- 1 x USB Type A male (upstream port)
- 1 x RJ-45 jack (downstream port)
- Power: Bus-powered
- Remote Unit:
- 1 x USB Type A female (downstream port)
- 1 x RJ-45 jack (downstream port)
- Self-powered (power)
- Local Unit:
- Cable Length:
- 1.0' / 0.3 m (built-in cable)
- 196.9' / 60.0 m (connecting cat cable)
- Interconnect Cables: Standard Cat5/5e/6 network cable
- Data Transfer Rates:
- High Speed: 480 Mb/s
- Full Speed: 12 Mb/s
- Low Speed: 1.5 Mb/s
- Power: 5 V, 2.6 A
- Operating Temperature: 32 to 104°F / 0 to 40°C
- Housing: Plastic
- Weight: 0.15 lb / 0.07 kg
What's Included
- ATEN UCE260 USB 2.0 Extender
- Remote Unit
- Power Adapter
- Product Type:
- USB Extenders
