Warranty: 2 Years
The VC840 HDMI to 3G/HD/SD SDI Converter provides a professional way to exchange high definition signals in real time. The SDI and HDMI signal conversion is 100% digital and guarantees no loss of quality for both the audio and video transmission. The VC840 provides 2 low jitter SDI outputs for dual display. The VC840 is the most dependable way to convert signals with confidence when monitoring in any post or broadcast application.
Key Features
- Converts an HDMI input signal to 3G/HD/SD-SDI formats in real time while avoiding transformation loss for both audio and video signals
- Supports additional analog stereo audio and coaxial digital audio
- HDMI (Deep Color)
- LED indication of power and signal status
- Supports an SDI distance of up to 90M (3G-SDI), 150M (HDSDI) or 300M (SD-SDI) of RG6
- Supported SDI formats:
- SD-SDI (SMPTE 259M, up to 270Mbps)
- HD-SDI (SMPTE 292M, 296M, up to 1.485Gbps)
- 3G-SDI (SMPTE 424M, 425M level A, up to 2.97Gbps)
- Video Support:
- 525i@59.96, 625i@50
- 720p@50/59.94/60
- 1080i@50/59.94/60
- 1080p@23.97/24/25/29.97/30/50/59.94/60
- Supports 8 audio channels @ 48kHz rate
- Offers 2 low-jitter SDI outputs for dual display
- Features automatic detection of 3G/HD/SD-SDI signals
- Reclocking SDI signals for cascading and thus longer transmission
- Locking power connector for secure communications
- Selectable EDID settings and EDID learning mode
Technical Specifications
- Video Input
- Interfaces: 1 x HDMI Type A Female (Black)
- Impedance: 100 Ω
- Max. Distance: 3m at 1920*1080@60 (4:4:4)
- Video Output
- Interfaces: 2 x BNC (Gold)
- Impedance: 75 Ω
- Video
- Max. Data Rate: 2.97 Gbps
- Max. Pixel Clock: 148.5 MHz
- Supported Resolutions:
- NTSC@59.96Hz, PAL@50 Hz;
- 720p@50/59.94/60 Hz;
- 1080i@50/59.94/60 Hz;
- 1080p@23.97/24/25/29.97/30/50/59.94/60 Hz
- Max. Distance: 90m (3G-SDI); 150m (HD-SDI); 300m (SD-SDI)
- Audio
- Output:
- Analog: 2 x RCA (Red/White)
- Digital: 1 x RCA (Yellow)
- Output:
- SDI Formats
- SD-SDI (SMPTE 259M, up to 270 Mbps)
- HD-SDI (SMPTE 292M, 296M, up to 1.485 Gbps)
- 3G-SDI (SMPTE 424M, 425M level A, up to 2.97 Gbps)
- EDID Settings
- EDID Mode: Learn
- Connectors
- Power: 1 x DC Jack
- Power Consumption
- DC5V:3.225WBTU/h
- Note:
- The measurement in Watts indicates the typical power consumption of the device with no external loading.
- The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
- Environmental
- Operating Temperature: 0-40°C
- Storage Temperature: -20 - 60°C
- Humidity: 20 - 90% RH, Non-Condensing
- Physical Properties
- Housing: Metal
- Weight: 0.29 kg ( 0.64 lb )
- Dimensions (L x W x H): 12.20 x 10.70 x 3.04 cm (4.8 x 4.21 x 1.2 in.)
What's Included
- 1x VC840 HDMI to 3G/HD/SD-SDI Converter
- 1x Power Adapter
- 1x User Instructions
