Warranty: 2 Years
The VE601T DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability.
* Compatible HDBaseT Receiver Units: VE601R, VE801R
Key Features
- HDBaseT connectivity – extends a DVI connection up to 70 m
- Superior video quality – 1920 x 1200 @ 35 m (Cat 5e / 6) / 40 m (Cat 6a) ; 1080p @ 60 m (Cat 5e / 6) / 70 m (Cat 6a / ATEN 2L-2910)
- DVI (3D, Deep Color); HDCP 1.4 compliant
- HDBaseT Anti-Jamming – resists signal interference during video transmission
- Plug-and-play
- Rack-mountable
Technical Specifications
- Video Input
- Interfaces: 1 x DVI-D Female (White)
- Impedance: 100Ω
- Max. Distance: Up to 1.8m
- Video
- Max. Data Rate: 10.2Gbps (3.4Gbps per lane)
- Max. Pixel Clock: 340 MHz
- Compliance:
- DVI (3D, Deep Color)
- HDCP compatible
- Max. Resolutions / Distance:
- Up to 1920 x 1200@35 m (Cat 5e/6) / 40 m (Cat 6a/ATEN 2L-2910 Cat6);
- 1080p@60 m (Cat 5e/6) / 70 m (Cat 6a/ATEN 2L-2910 Cat6)
- Connectors
- Power: 1 x DC Jack with locking
- Unit To Unit: 1 x RJ-45 Female
- Power Consumption
- DC5V:1.84W:9BTU/h
- Note:
- The measurement in Watts indicates the typical power consumption of the device with no external loading.
- The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
- Environmental
- Operating Temperature: 0-50 °C
- Storage Temperature: -20 - 60 °C
- Humidity: 0 - 80% RH, Non-Condensing
- Physical Properties
- Housing: Metal
- Weight: 0.25 kg ( 0.55 lb )
- Dimensions (L x W x H) with bracket: 10.20 x 8.70 x 3.00 cm (4.02 x 3.43 x 1.18 in.)
- Dimensions (L x W x H) without bracket: 9.42 x 6.60 x 2.90 cm (3.71 x 2.6 x 1.14 in.)
What's Included
- 1x VE601T DVI HDBaseT-Lite Transmitter
- 1x Power Adapters
- 1x User Instructions
- Product Type:
- Video Extenders
