ATEN CAMLIVE HDMI to USB-C UVC Video Capture Adapter

ATEN
SKU:
UC3020-AT

Pricing available upon request

Warranty: 2 Years
Current Stock:

"CAMLIVE" is an HDMI UVC Video Capture device to send unencrypted HDMI video to your USB-C or Thunderbolt 3 laptop (or USB-A with the included adapter). It’s compliant with latest USB 3.1 Type-C specification.

CAMLIVE is designed to Plug & Play. Its built-in UVC and UAC standard support allows system operation without installing drivers and, at the same time, delivers eye-popping, highquality video on Windows and Mac systems at 1080/60fps. By sending captured RAW data, you can enjoy video editing or live streaming with various popular third-party video-editing software/platforms - Open Broadcaster Software (OBS), Xsplit,Twitch, YouTube, Facebook, to name a few.

Having a slim and aesthetic design, CAMLIVE provides you with an enjoyable, high-quality live streaming/video editing experience with style whether at work or on the go.

Key Features
  • Captures Unencrypted HDMI
  • Up to 1920 x 1080 Resolution at 60 fps
  • USB 3.1 Gen-1 Type-C Interface
  • Built-In UVC and UAC Support
  • Plug-and-Play Functionality
  • Windows and Mac Compatible
  • Compatible with Popular Software Apps
  • USB Type-C to Type-A Adapter Included

Technical Specifications

  • Input
    • Compliance: HDMI 1.4b, up to 1920 x 1080p60 (Non-HDCP)
    • Input Resolutions:
      • 1080p
      • 720p
      • 480p
    • Color Space: YUV2, RGB
    • Audio:
      • 16-Bit PCM Audio
      • 32 , 44.1, and 48 kHz
  • Output
    • Video: Up to 1080p UVC Video Stream with UAC Audio (Uncompressed Video Stream is Only Available on USB 3.1 Connection)
  • System
    • Minimum Hardware Requirements:
      • CPU: Intel i3 Dual Core 2.8 GHz or Higher
      • RAM: 4 GB or More
    • OS Support:
      • Windows 7 and Above with UVC Support
      • macOS X 10.13 and Above with UVC Support
  • Environmental
    • Operating Temperature: 32 to 104°F / 0 to 40°C
    • Storage Temperature: -4 to 140°F / -20 to 60°C
    • Humidity: 0 to 80% RH, Non-Condensing
  • Physical
    • Housing: Aluminum
    • Dimensions: 2.9 x 1.6 x 0.5" / 7.3 x 4.2 x 1.4 cm
    • Weight: 1.5 oz / 42 g

What's Included

  • ATEN CAMLIVE HDMI to USB Type-C UVC Video Capture Adapter
  • USB Type-C to Type-A Adapter
Product Type:
HDMI Converters
