ATEN 2-Port PS/2 VGA KVM Switch

ATEN 2-Port PS/2 VGA KVM Switch

ATEN
SKU:
CS82AC-AT

Pricing available upon request

Warranty: 2 Years
Current Stock:
Description

CS82A is a KVM switch with built-in PS/2 on each of the front and rear panels. It can control 2 servers via a single console and allows users to switch between computers via the buttons on the front panel of the switch or the hotkey configuration on the keyboard. It is the simplest and most convenient solution for multi-computer management. The sturdy, durable and small enclosure design is its important feature.

Key Features

  • One PS/2 console controls 2 computers.
  • Computer selection via front panel pushbuttons and hotkeys.
  • Superior video quality- up to 1920 x 1440; DDC2B.
  • Supports Microsoft IntelliMouse, Logitech MouseMan, FirstMouse and IBM Scrollpoint Mouse.
  • Compact, Sturdy, Durable Metal Housing.
  • Keyboard and mouse emulation for error free booting.
  • Auto Scan function to monitor computer operation.
  • Non-powered.
  • OS Compatibility: DOS, WIN 98, WIN ME, WIN NT, WIN 2K, WIN XP, WIN 2003, Windows Vista, LINUX. Mac 8.6/9/10 and SUN Solaris 8/9 (with optional adapter).

Technical Specifications

  • Computer Connections: 2
  • Port Selection: Hotkey, Pushbutton
  • Connectors
    • Console Ports:
      • 1 x HDB-15 Female (Blue)
      • 1 x 6-pin Mini-DIN Female (Purple)
      • 1 x 6-pin Mini-DIN Female (Green)
    • KVM (Computer) Ports:
      • 2 x HDB-15 Male (Blue)
      • 2 x 6-pin Mini-DIN Female (Purple)
      • 2 x 6-pin Mini-DIN Female (Green)
    • Power: 1 x DC Jack
  • Switches
    • Ports: 2 x Pushbutton
  • LEDs
    • Online: 2 (Orange)
    • Selected: 2 (Green)
  • Emulation
    • Keyboard / Mouse: PS/2
  • Video: 1920 x 1440 @ 60Hz; DDC2B
  • Scan Interval: 3, 5, 10, 20 seconds
  • Power Consumption
    • DC9V:0.3W:6BTU/h
    • Note:
      • The measurement in Watts indicates the typical power consumption of the device with no external loading.
      • The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
  • Environmental
    • Operating Temperature: 0-50°C
    • Storage Temperature: -20-60°C
    • Humidity: 0 - 80% RH, Non-condensing
  • Physical Properties
    • Housing: Metal
    • Weight: 0.54 kg ( 1.19 lb )
    • Dimensions (L x W x H): 14.00 x 8.80 x 5.55 cm (5.51 x 3.46 x 2.19 in.)

What's Included

  • 1x 2 Port KVM Switch
  • 2x PS/2 KVM Cables
  • 1x User Manual

Additional Information
Product Type:
KVM Switches
